Mission Magnum Tsbv 6x5x11 Vertical Centrifugal Sand Pump - China

Design Features:

• The TSBV series open-vane impeller eliminates recirculation that occurs in closed impellers.

The impeller is designed to reduce turbulence, lower radial and thrust loads, and provides a smooth flow of fluid through the pump.

Housing wear is reduced by eliminating the high scrubbing action that occurs on conventional pumps.

The SB240 series impeller is designed to allow fluid leaving the impeller to blend with recirculating fluid to reduce abrasive wear of the casing.

The open-vane impeller has no exposed impeller nuts or shaft threads.

The impeller is screwed on and the threads are protected by ano-ring.

The SB240 series pump and impeller are designed to increase service life many times over that of conventional pumps.

• The TSBV series shaft has a greater diameter to provide heavy-duty performance with minimal shaft deflection.

The replaceable shaft sleeve allows the wear from the packing to be renewed without replacing the entire shaft.

The shaft sleeve and mechanical seal can be replaced 4without removing the shaft from the pump

• The TSBV series bearings are designed for easy maintenance.

The outboard bearing assembly is comprised of two angular contact bearings with high thrust load ratings and zero end play.

The inboard bearing is a heavy-duty, double row ball bearing with high radial load capacity to compensate for the larger impeller sizes and heavy-duty applications.

The SB240 series only uses the best bearings available.

Tobee® TSBV Mission Magnum Sand Pumps Application: • Desanding and desilting

• Degassing

• Supercharging

• Centrifugal feed

• Mud cooling towers

• Wash-down

• Chemical, refinery, industrial, construction and agricultural applications

• Underground Construction
