Horizontal Centrifugal Desulfurization Pump - China

single-stage and horizontal centrifugal Desulfurization pump

Structure Characteristics

TLR FGD pump is a single-stage and horizontal centrifugal pump.

It is mainly used as the circulating pump in the wet FGD device in absorbing tower.

The double-shell structure, rubber sleeve, and the A49 metal impeller have a wide flow range.

high efficiency and energy saving.

Applicable working conditions

The main circulating pump for flue gas desulfurization equipment used in coal-fired power plant units is especially suitable for lime gypsum desulfurization process.

Performance range

Discharge range: 500 ~ 1000mm

Flow range: 3700~13000m3/h

Head range: 15 ~ 35m

Single Stage Pump Supplier: shijiazhuang mainte slurry pump co., ltd

TLR FGD Pump Parameters

TLR Pump Code Head(m3/h) FlowQ(m) Rotating speed n(r/min) Efficiencyη(%) NPSHr(m) Discharge diameter(mm) Suction diameter(mm)

350X-TLR 1600 25 960 82 4.5 350 400

400 X-TLR 2500 28 725 83 5.0 400 450

500 X-TLR 3800 26 725 85 5.0 500 500

600 X-TLR 6300 25.5 625 88 5.5 600 700

700 X-TLR 6850 27 485 87 6.0 700 800

800 X-TLR 9360 31 485 90 7.0 800 900

900 X-TLR 13000 30 485 90 8.5 900 1000

Shijiazhuang mainte slurry pump Co., Ltd. Is a scientific and technological innovative pump production company integrating R & D, production, marketing and service of desulfurization pump, slurry pump, dredging pump, sewage pump, non blocking centrifugal pump, submersible slurry pump, clean water pump and other products.

The company has strong technical production capacity and perfect service system.

More information visit our website.

Company Contact:

• Posted By: shijiazhuang mainte slurry pump co.,ltd

• Phone: 13931129905

• Address: No.176 Huai'an East Road, Yuhua District, Shijiazhuang, Shijiazhuang City, Hebei , China

• Email:

• Website: https://www.maintepump.com

• Business Description: Shijiazhuang mainte slurry pump Co., Ltd. Is a scientific and technological innovative pump production company integrating R & D, production, marketing and service of desulfurization pump, slurry pump, dredging pump, sewage pump, non blocking centrifugal pump, submersible slurry pump, clean water pump and other products.

  The company has strong technical production capacity and perfect service system.

  The products are mainly used in FGD, electric power, mining, metallurgy, dredging, coal, chemical industry, paper making, sewage treatment, building materials, water conservancy engineering, biogas and other engineering projects.

  The products are not only sold in all provinces and cities, but also exported to Europe, America, Africa, Southeast Asia and other countries and regions.
