2000rpm Hydraulic Rotary Union Universal Pipe Fitting Stainless Steel - China
price: 500.00 Dollar US$
2000rpm Hydraulic Rotary Union universal pipe union fitting Stainless Steel Product Description A rotary joint, also referred to as a rotary joint or rotating joint, provides a mechanical seal between a stationary supply pipe and a rotating drum or cylinder to permit the flow of heat transfer media into and/or out of the rotating roll.
Heat transfer media typically used with rotary joints and rotating joints includesteam, water, hermal oil, coolant, airhydraulic oil.
BKR series rotary joint consists of two large precision bearings and seals principles of design using smooth, sealed bearing and wear to a minimum, extend the service life.
Specifications: Recommended medium heat conducting oil Available sizes 1/4" - 4"
Max.
pressure water
sizes 1/4" - 1 1/2" 50, 0 bar
size 2" 40, 0 bar
Max.
temperature
oil 400 °C
Max.
speed
sizes 1/4" - 3/4" 2000 RPM
size 1" 1500 RPM
sizes 1 1/4" - 1 1/2" 1500 RPM
size 2" 750 RPM Benefits: 1 - High-temperature, high-pressure resistant rotating pipe coupling 2 - Rugged-construction unions suitable for high pressure, high temperature thermic oil, steam 3 - The seal is imported from Germany, which guarantee the excellent performance of our rotary union.
4 - The design of detachable baseplate structure is convenient for the conversion between single and multi-passsages 5 - The use of graphite pallet balance the compensation of spring, hence it avoids the spring being corroded and prolongs the service life.
6 - Ideal for thermal oil and for considerably higher pressures, temperatures 7 - Hosing made of ductile cast iron and cover&rotor made of chrome steel 8 - Have high temperature resistant spring
Company Contact:
- Phone: +8613929708571
- Address: Floor 2, Unit C, Guangfa Industrial Park, Dananhai, Luotian Community, Songgang Street, Baoan Dist., Shenzhen , China
- Email:
Published date: August 28, 2018
- Business Description: JARCH is a professional Slip Ring & Routry Joint manufacturer in Shenzhen, China.
Since we were founded in 1998, we have been committed to innovating, developing and manufacturing high quality slip rings and providing perfect rotation solutions for customers around the world.
