Xc 880 Wire Bending Machine - China

Model: BD-1500

Power Supply: AC220V 50/ 60HZ

Size: L420xW300xH345mm

Weight: 31KG

Power: 130-200W

Productivity: 400—100 0pcs/h

Catheter diameter: 1.5mm10mm

Cutting Wire Core: 0.1-16

The last bend: more than 20 mm.

Stripping length: 0.1mm---99999.9mm

Stripping end: 0.1－100mm

Bending times: 13

Bending mode: Clockwise, counterclockwise, bending adjustable, 30 degrees, 45 degrees, 60 degrees, 90 degrees.

The same line can bend both sides at the same time.

The shortest type of U is 20mm.
