Xc 220 T Automatic Double Wires Stripping Twisting Machine Max 6mm2 - China

Feature:

1 - Electronic products tend to be light, thin, short and small, so the required wires tend to be thin, short and high precision.

2 - This machine can give full play to its greatest strengths.

The short line within 50MM, which used to be considered difficult to process, is not responsible now.

3 - Why is it difficult? At the same time, the speed of feeding, feeding, retracting, re-peeling and peeling can be set separately, and the isolation line can also be forced.

4 - Stripping to the end of 99MM, eliminating the previous isolation line can not be completely stripped and injured to the heart line.

Model: XC-220+T

size: 930 x 700 x 300 (size including installation tray straightener)

Weight: 33Kg

power: AC220V 50Hz/60Hz 450W (special voltage can be customized)

Processing Diameter: AWG16#~AWG32#(De pending on Wire Material and Structure)

Cutting length: 0.1-99999.9 mm

Peeling length: front end: 0-30 back end 0-100 (more than 30 need half peeling)

Cutting tolerance: (+0.2+0.003*L) mm (L equals length)

Blade Material: Tungsten Blade or High Speed Blade

speed: 13000 pcs/h (100mm long, uniformly 3 mm full stripping before and after)

Driving mode: 2-phase hybrid stepping motor

Processing Wire: PVC, VSF, Teflon, Glass Fiber, etc.

Wire range: Can be strip and twist two wires at once time (less than 1.5mm2)

Can be strip and twist a wire (Max.

6mm2)
