Top Hat Channel Cold Roll Forming Machine For Steel Furring Profiles - China

Top Hat Channel Cold Roll Forming Machine for Steel Furring Channel Profiles

Forming Shape: Hat Channel Profile Shape with Punching Holes

Working Flow

Decoiler-->Fedding& amp;Leveling-->Punchin g-->Roll Forming-->Cut-to-lengt h-->Output Table

Coil Material

Thickness: 1.5mm-2.5mm

coil feeding width: Custom-made

Material: GI.

Carbon Steel

Pinch Feeding&Leveling

Feeding roller: 4 rollers

Leveling roller: 7 rollers (upper 3 rollers, bottom 4 rollers)

Punching: Hydraulic Punching

Punching Material: Cr12Mov, quenched, HRC58-62

Main roll forming machine

Forming stations: 14 stations(Depend on Profile)

Roller material: GCr15 steel, HRC58-62

Diameter of shaft: 80mm

Shaft material: High grade 45# steel

Forming speed : 0-15m/min

Cutting

Cutting system: Hydraulic cutting

Material of blade mould: Cr12, quenched58-62

Length olerance: 10m+/-1.5mm

Output table

Table type: simple nonpower type

Function: support the finished panels
