Tobee® 6 4e Ahr Rubber Slurry Pump - China

Tobee® 6/4E-AHR Rubber Lined Slurry Pump is cantilevered, horizontal, centrifugal with double casing slurry pump.

They are designed for the handling of highly abrasive, high-density slurries.

The wet parts of 6x4 slurry pumps are made of natural rubber, which could be replaceable wear-resistant parts.

The discharge side can be oriented to any of the eight different positions.

The shaft seals may adopt packing gland seal, expeller seal and mechanical seal.

Design Features: √ Bearing assembly – A large diameter shaft with short overhang minimizes deflection and contributes to long bearing life.

Only four through bolts are required to hold the cartridge type housing in the frame.

√ Liners – Easily replaceable liners are bolted, not glued, to the casing for positive attachment and ease of maintenance.

Hard metal liners are completely interchangeable with pressure molded rubber.

Elastomer seal rings back all liner joints.

√ Casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.

Company Contact:

• Posted By: HEBEI TOBEE PUMP CO., LIMITED

• Phone: 15633815619

• Address: No. 266, Tianshan St, High-tech Zone, Shijiazhuang City 050000, Hebei , China

• Email:

• Website: https://www.slurrypumpsupply.com/

• Business Description: Capacity

  Tobee® Pump has a wealth of experience in the manufacturing and service of pumps and accessories; in fact Tobee® Pump has machinery manufacturing experience of over 45 years having achieved great success with R&D and manufacturing of Pumps for more than 30 years.

  The annual production capacity of pumps in our factory surpasses 10,000 easily.

  Tobee® Pump has a tremendous market share that covers more than 120 cities in China including many provinces and autonomous regions and more than 80 countries.
