Super Machine Tool - China
price: contact company for price
Super Machine Tool
cone machining CNC Machine Tool Description
Type Unit DK77120 DK77120B DK77120F DK77160
Worktable Size (W*L) mm 1900×1310 2100×1310 2300×1310 2300×1670
X, Y-axis trip(Y×X) mm 1200×1600 1200×1800 1200×2000 1600×2000
U, V-axis trip(U×V) mm 70×70
Max load weight kg 4500 5500 6000 8000
Max linear cutting thickness mm 1000 1000mm(930) 1000mm(930) 1000mm(930)
Machined taper/work piece thickness 12°/80mm
Z-axis elevation mode Manual/electric elevation
Type of guide track Slide guide
Electrode wire diameter range mm Ф0.15~0.20mm
Wire speed m/sec 1~11.4m/sec 7 frequency conversion adjustable
Machining accuracy mm ≤0.015
Max cutting efficiency mm²/min ≥120
Optimum surface roughness um Ra≤2.5
Control mode X, Y, U, V stepper motor
Number of control axis Four-axis linkage
Min instruction unit mm 0.001
Power supply Super Machine Tool Three-phase four-wire 380VAC/50HZ
Max operating current A 12
Machine tool power consumption kw ＜2
Working fluid DX-1 DX-4 Nanguang-1
Working fluid tank volume L 55
Work liquid filtrate way Strainer
Host weight kg 8000 9000 10000 12000
Host outline size mm 4000×3100×2800 4000×3300×2800 4000×3500×2800 4500×3500×2800
More information can view Hifactory.
Company Contact:
- Posted By: Taizhou Wenjie CNC Equipment Co., Ltd.
- Phone: +8652386663100
- Address: No.28 Xingling road, Hailing industrial park, Taizhou , Jiangsu province, China
- Email:
- Website: https://www.wjcncmachine.com
Published date: October 8, 2019
- Business Description: Taizhou Wenjie CNC Equipment Co., Ltd., formerly known as Taizhou Hailing District Zhongxing CNC Machine Tool Factory, an established enterprise specialized in the creation of CNC linear cutting machines, is located in Taizhou, Jiangsu, where is known as the hometown of Mei Lanfang, master of Peking Opera.
Situated in Hailing Industrial Park, Taizhou, it is a vice president company of Taizhou Special Processing Machine Association and a high-tech enterprise in Taizhou, integrating R&D, creation, operation and sales.
