MZ150 Portable Gate Valve Grinding Machine

Portable Valve Grinding and Lapping Machine For Gate Valves

Portable Valve Grinding and Lapping Machine Technical indicators

Applicstion: Gate Valve Seat, Gate Valve Core.

Grinding diameter: D=Dia50-Dia180mm adjustable

Valve DN: DN50-150mm

The electrical power: 1100W (Electric motor)

The greatest adjustment depth: 420 mm

Input voltage: 220 V Operating weight: 20 kg

The smallest broaching size: B = 38mm

1 - Summarization

MZ Portable Valve Grinding Machine for grinding gate valve is a new generation of products that is adeveloped to adapt to on-site maintenance gate valve.

It has the advantages as below: the reduction of labor intensity, improving labor efficiency, replacing imported products, educing the maintenance cost.

It is widely used in petroleum, chemical industry, steel mills, power plants and so on.

1) small volume.

Light weight, easy to carry.

2) installation is simple, the structure of product is combined type, easy disassembly, transvestite.

3) easy to operate.

Valve seat, valve core can be grinded.

4) high grinding efficiency, good quality.

Using advanced grinding materials, grinding efficiency is 10 to 30 times that of the manual grinding, can make the contact area of more than 95%.

High precision grinding quality makes the contact area to the level of new valve.

5) it is suitable for on site repair in a complicated environment which saves the overall disassembling of valve.

2 - Technical indicators

Item MZ-150 MZ-250

Grinding Range(mm) Dia 50-180 Dia95-270

Voltage(V) 220 220

Power(W) 1100 1100

Frequency(HZ) 50 50

Max Grinding Depth(mm) 420 600

Valve sealing face min gap(mm) 38 45

Gross Weight(kg) 20 31.5 Portable Gate Valve Grinding Machine, Valve Core & Seat Grinder

Hot Sale Various High Quality Valve Grinder, Valve Test Bench, Pipe Beveling & Cutting Machine.

The portable & Stationary Valve Grinding Machine is suitable for Gate Valve, Globe Valve, Safety Valve.

As fames China Valve Seat grinded Machine, High quality and factory price will give you.
