Laser Welding Machine Industrial Welder System 150w 300w Tete Dpf W150 - China

Features 1 - Flexible and convenient for processing, easy for system integration

2 - Energy negative feedback technology is employed to improve the repeatability of the energy transmitted by the laser

3 - The waveform can be adjusted according to the shape and material of the workpiece.

4 - The light beam can be split based on energy or time to realize simultaneous or sequential welding.

5 - It can communicate with other systems through I/O connectors.

Specification

Model DPF-W150 DPF-M300

Wavelength 1070nm

Average Power 150W 300W

Max.

Peak Power 1500W 3000W

Max.

Energy 15J 30J

Pulse Width 0.2~50ms

Pulse Frequency 1-2500Hz

Cooling Mode Air cooled

Ambient Environment Temperature: 10ºC~40ºC

Humidity: 5%~75%

Power Consumption 1200W 2300W

Electrical Connection Single-phase 220V/50~60Hz

Weight 100Kg/200Kg Note: In the interest of technical progress, we reserve the right to make technical changes without notice.

Company Contact:

• Posted By: Shenzhen TETE Laser Technology Co.,Ltd.

• Phone: +8615818534315

• Address: 9-11F, West Block No.1 Building, Tai Chen Guang Communications Factory, Shenzhen , Guangdong , China

• Email:

• Business Description: TETE Laser has its independent technology and R&D center.

  It owns lots of patents and software copyrights.

  At the same time, it is a participator of 863 national research projects.

  Up to now, TETE Laser has manufactured and sold series of industrial laser processing system and provided professional industrial laser solutions to domestic and overseas customers.

  Its main products are high precision laser cutting/drilling system, 3D laser marking system, IC specialized double tracks automatic/semi-automatic laser marking system, DPF series-diode pump fiber laser marking system, DPY series-diode side pump laser marking system, UV/Green laser system, DPV series-diode end pump fiber marking system, DPF-W series fiber laser welding system, LPY series-laser welding system, Laser soldering system, CO2 Series-laser marking/cutting system, CO2 Series-platform laser cutting system.

  These products are widely used for laser marking, laser welding and laser cutting in various industries.

  Kinds of laser series meet different processing requirements.

  TETE Laser is certified to ISO9001 and its products have CE approval.

  It is appointed by Shenzhen government of the software enterprise, high and new technology company.

  TETE Laser has developed to a professional industrial laser processing system manufacturer with abundant technologies.
