Hybrid Vertical Injection Molding Machine Dv 1600 2r Ce - China

hybrid vertical injection molding machine DV-1600.2R.

CE The CE series DENICE:

approved by the European Union, equipment collection area is designed with ergonomic design.

The safety protection devices in all parts are effective in preventing accidental accidents.

Optional rotary table series DENICE injection machine, increase production efficiency and safety of the operators.

Specification

Model Unit DV-1600.2R

( Injection Unit ) Screw diameter mm Ф50 Ф55 Maximum injection pressure Kg/cm2 1856 1534 Theoretical shot volume cm3 471 570 Maximum shot weight(PS) g/Oz 420(14.8) 509(17.9) Injection rate cm3/sec 157 190

( Clamping Unit ) Clamping force ton 167 Rotary Table Diameter mm 1400 tie bar distance mm - Minimum mold thickness mm 250/350(Can be customized according to customer requirements) Opening stroke mm 300 Open daylight mm 550/650(As required) Ejector force T 4.0(Can be customized according to customer requirements) Ejector stroke mm 125

( Others ) Pump motor power Kw 18.5 Hydraulic system pressure Kg/cm2 140 Barrel heating power Kw 10.8 Total wattage Kw 29.3 Oil tank capacity L 800 Machine weight (approx.

) T 7.5 Machine dimensions(approx.

) m 3.6×1.8× 3.9

Company Contact:

• Posted By: Hangzhou Denice Machinery Co.,Ltd

• Phone: 86-571-63501868

• Address: Shangguan Xiang Special Industrial Zone ,Fuyang District, Hangzhou , Zhejiang , China

• Email:

• Website: https://www.denice.com.cn/

• Business Description: Hangzhou DENICE Machinery Co., Ltd. is one of the most professional manufacturers of vertical injection molding machines in China.

  The company specializes in the production of high quality and high precision vertical injection molding machines that the clamping force is from 15 tons - 650 tons, and the injection volume is from 35 grams, 8000 grams.

  We have standard series machine, single slide plate series, double slide plate series and rotary table series injection molding machine.

  In addition, to improve the work efficiency and to the different needs of customers in different industry, we have special offer special machine with industry characteristics, such as: Special machines for golf, High-speed & high pressure plastic injection machines, J series energy-saving plastic injection machines, Liquid silicon rubber plastic injection machines(LSR), BMC, Bakelite injection molding machines, bi-color (multicolor) injection molding machines, APC series full automatic belt molding machines, and so on.

  Our products are widely used in automobile manufacturing, medical equipment industry, cosmetics industry, cutting tools, sanitary ware, furniture, toys, daily necessities, baby supplies, electronic connectors, optical lenses, back plate, watch movement gears, soles, color plate, hose and hard tube, and so on.

  Uphold the quality first, service customers, innovation management concept, our company continues to improve ourselves, constantly improve the quality of service, and create best value for our customers.
