High Quality Reasonable Price Good After Service 1 Year Warranty More Than 10 Years Experience - China

High Quality •Reasonable Price •Good after Service •1 Year Warranty •More Than 10 Years Experience

Product Details:

Place of Origin: China

Brand Name: TECHWELL

Certification: CE

Model Number: TW-GTM

Product Details；

Different Glazed tile roll forming machines can produce different shapes of steel tile roof sheets in various thickness and colors.

Steel tile roof sheets are the new substitutes for traditional clayey, concrete tiles.

They are popular because of their low cost, short building period, re-cycle use, and elegant appearance.

They are used a sthe roof of villas, luxury houses, theatres, exhibition centers, etc.

•This Glazed Tile Roll Forming Machine can rollform metal roof tiles.

After roll formed by this glazed roof tile roll forming machine, the surface of metal roof glazed tile is very smooth and beautiful without any scratch on the surface of tile profile sheets.

•The Steel Glazed Roof Tile Roll Forming Machine is with fully automatic control system with PLC.

•Length, quantity of sheets is adjustable.

•Rollforming process: Decoiler, Rollforming, Pressing & Cut to length.

•Easy operation: Key in the length and quantity on the control panel.

•1 Year warranty, lifelong time service.

•We also can do a custom roll forming machine, we can design machines according to your specifications and profile drawings, all our machines are customized.

Main Specification:

 Material thickness: 0.3-0.7mm

 Material width: depend on customer’s requirement

 Decoiler Type: manual or automatical type ( depend on customer’s requirement )

 Weight Capacity Of Decoiler: 5 Ton

 Main Motor Power: 5.5 Kw

 Hydraulic Motor Power: 11 Kw

 Forming Station: 13-22 ( depend on profile drawing )

 Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.

 Main Axis Material: High grade 45#, quenched and heat treatment.

 Axis Diameter: ¢ 75mm

 Working Speed: 0-15 m/min

 Transporting Type: Chain Transmission

 Heat Treatment of Cutting Blade: HRC 50-60

 Type of Cutting: Hydraulic cutting

 Material Of Cutting Blade: C r 12

Company Contact:

• Posted By: Wuxi Techwell Machinery Co.,Ltd

• Phone: 86-15861597732

• Address: Jingshi Road, Xibei Town, Xishan District, Wuxi , Jiangsu , China

• Email:

• Business Description: Wuxi Techwell Machinery Manufacturing Co., Ltd is a professional manufacturer specializing in the developing and exporting of cold roll forming machines and insulated sandwich panels machines and slitting cutting machines.

  Roll Forming Machines: Metal roof wall roll forming machine, steel tile roll forming machine, dual level roll forming machine, C/Z/U/L shaped steel roll forming machine, drywall stud and track roll forming machine, floor deck roll forming machine, guardrail roll forming machine, downspout roll forming machine, gutter roll forming machine, portable downpipe machine, portable gutter machine, roller shutter door roll formng machine, k-span arch roof roll forming machine, Slitting cutting machine line, roof curving machine, stacker machine and so on.

  Insulated Sandwich Panel Machines: PU sandwich panel machine, rubber belt pu sandwich panel machine, continuous pu sandwich panel machine, EPS sandwich panel machine, rock wool sandwich panel machine, mineral wool sandwich panel machine and so on.

  Our machines are very popular in Middel East, South East Asia, Africa, South America and East Europe, such as India, Iran, Australia, Canada, Bangladesh, Indonesia, Myanmar, Chile, Saudi Arabia, Brazil, Romania, Dominica, Panama, Turkey, Russia, Uraguay, Souch Africa, U.A.E, Ghana, Malawi, Nigeria, Zambia.

  Our Goal is to supply best quality machine and best service with reasonable price for our customers.

  We sincerely hope to cooperate with worldwide customers for our mutual success, and we warmly welcome to visit our factory.
