Ezcad3 Laser And Galvo Control Software - China

It has a completely new architecture, significantly speeding up data processing speed, and can meet high-precision technical requirements.

Combined both 2D and 3D functionality.

Added high-performance motion control expansion capabilities, supports large-format processing control.

Connects via Ethernet, with unrestricted transmission distance, enabling remote control operations.

Supports various mainstream laser types.

onfigurations

Software Kernel 64 Bit

Laser Supports CO2, YAG, FIBER, SPI, QCW, CW, etc., and can adjust current, pulse frequency, duty cycle, and other parameters based on different laser parameters through software.

Can display the laser status in real-time, and JCZ laser digital communication protocol 1.0 supports almost all lasers available in the market.

Red Light Display Supports red light as an indicator

Password Control Supports password protection to prevent unauthorized parameter changes

IO Control Added port control functionality for easy automation of your machine

Galvo Calibration 3D calibration, traditional trapezoidal correction, barrel (pillow) correction, and parallelogram correction.

Specialized calibration software to achieve extremely precise calibration results.

Fill Background fill, circular fill, arbitrary angle fill, cross fill, adjustable margins, borders, and spacing.

Supports 8 layers of filling, with independent parameter settings for each layer

Editing Functions Multi-layer, 3D curve marking, slicing, dynamic filling, 3D curve projection, surface wrapping, bitmap to embossing, arbitrary curve text, arbitrary graphic drawing/editing, scatter/combine, group/ungroup, undo/redo, welding, trimming, cross, alignment, automatic curve connection, etc

Text Input Function Supports TrueType fonts, single-line fonts (JSF), dot matrix fonts (DMF), SHX, and supports user-created font libraries

256 Layer Processing Parameters Highly customizable for easy multi-parameter marking

Barcodes and QR Codes Code39, EAN, PDF417, DATAMATRIX, QR, PostNet, PL ANET, UK Royal Mail 4 state customer, AZTECCODE, MicroQRCODE, VERICODE etc Bitmap Files BMP, JPG, JPEG, GIF, TGA, PNG, TIF, TIFF, Supports segmented processing

Variable Text Fixed text, date, time, keyboard input, skipping numbers, list files, dynamic files, supports Excel sheets, TXT files, serial communication, and network communication

Multi-Language Support Built-in Chinese, English, Korean, Japanese, French, German; can be easily localized by language packs for translation

Optional Features Four-axis point-to-point motion, Dual-axis splicing, flying marking, software secondary development

Calibration Table Supports loading and switching between up to 4 calibration tables simultaneously

Multi-Layer XY Plane Calibration Supports, greatly improving the XY plane calibration accuracy of 3D calibration

Offline Mark Supports switching and processing of up to 16 offline layers

Online Circular Arc Interpolation Commands Supports, for high-precision small circle processing

Three-Dimensional Model Files STL, DXF

Processing Functions Large-format dynamic focusing, projector positioning, multi-axis expansion, estimated processing time, ultra-fast point-like 2D barcode marking, uniform fill function, gradual power and speed control, circular and sine curve jitter, material parameter assistant function
