Cold Bending Machine For Angles And Plates - China

CNC Heating/Cold Bending Machine for Angles And Plates, CNC Heating Bending Machine for Plate, CNC Cold Bending Machine for Plate, CNC Cold Bending Machine for Angle

CNC Machine for Steel Tower

APPLICABLE INDUSTRY: The machine is mainly used for bending angles mainly in the field of power and telecommunication industry.

ADVANTAGES:

This machine is equipped with full set of moulds, replacing moulds in fast speed.

CNC technology controls stroke; memorized working function can repeat process any time.

High-precision workpiece, saving labors.

★ All of these models can be customized according to customer requirements.

Model LQ20

Max.

Bending Force (kN) 3150

Angle Bending Size (mm) Both Faces of Inner and External 50*50*3~200*200*20 Side Face of External 50*50*3~200*200*14 Side Face of Inner 50*50*3~200*200*12

Bending Degree (°) Both Faces of Inner and External 180°±50° Side Faces of Inner and External 180°±40°

Max.

Width * Thickness (mm) 700*20

Min.

Bending Degree (°) 90°

CNC Axis 1

Hydraulic Unit Motor Power (kW) 22

★ All of these models can be customized according to customer requirements.

Hot Sale cnc machine for drilling, punching, milling, shearing, sawing, bending, roll forming, hole processing.

The Machine is used for Plate, Angle, Flange, Connection Boards.

For more product information, please visit our website.

Company Contact:

• Posted By: Jinan Fast CNC Machinery Co., Ltd

• Phone: 0086-15098878331

• Address: NO.8521 WEST JINGSHI ROAD HCANGQING DISTRICT, JINAN,shandong,China, JINAN , shandong , China

• Email:

• Website: http://www.jnfate.com

• Business Description: JINAN FAST CNC MACHINERY CO., LTD is devoted to design and manufacture complete processing machines working on the H-beam, U-beam, angles, plates and tubesheets, flanges and other steel profiles with punching, drilling, milling, boring function.

  JINAN FAST CNC MACHINERY CO., LTD is a professional manufacturer of profile and plate material auto-processing line and machinery.

  MAIN PRODUCTS: CNC full-automatic angle steel processing line, CNC joint plate punching& drilling machine, High-speed CNC drilling& milling machine for tube sheet/flange (PZG), CNC Beam Drilling machine (SWZ), CNC plate drilling& milling machine，CNC drilling& milling tapping machine, Gantry type drilling& milling& boring machine center, double-column rotation angle band-sawing machine, Angel notching machine, (Rolling type) Angle straightening machine, Hydraulic angle cutting machine, Hydraulic marking machine, Plate chamfering ( beveling) machine, Universal& special purpose hydraulic machines, etc.

  Focusing on customers value and requirements, JINAN FAST CNC MACHINERY CO., LTD is always ready to establish friendly business relationship with old and new customers for a brilliant future.

  Other Business--Precision Hole Processing

  Drilling sieve plate processing such as paper sieve plates, pulp filter sieve plates, mud extruder sieve plates, mining machinery sieve plates, and environmental protection equipment separating sieve plates, dehydration sieve plates, and vibration sieve plates.

  Drilling pressure container tube plates and stainless steel plates.
