Automatic Paper Embossing Machine Model Yw E - China

Product description:

The automatic paper embossing machine with the functions: automatic feeder & auto collecting picker.

Full automatic control in processing, adopt frequency governor, automatic hydraulic system and pneumatic blade, it is characterized by controllable speed, double-sheet control, automatic counting, etc.

Its average can range from 3000~5000pc/h.

It is applied to embossing the sheet surfaces of batches like packing products, playing cards, gift cards, golden and silver card paper, etc.

Optional collector:

-Auto vibrating collector

-Manual collecting table Main technical parameter:

Model: YW-720E / YW-920E / YW-1150E / YW-1300E

Max.

embossing speed: 80m/min

Max.

embossing width: 680mm / 880mm / 1000mm / 1180mm

Paper range: >160gsm

Operation pressure: 2-10Mpa

Main motor pressure: 14kw / 15kw / 16kw / 18kw

Vacuum pressure: 0.06Mpa

Air source pressure: 0.8-1.0Mpa

Overall dimension(L*W*H): 4800*1500*1800mm / 4800*1700*1800mm / 4800*1800*1800mm / 4800*2000*1800mm

Machine weight: 2800kgs / 3500kgs / 4200kgs / 5000kgs
