Mini Screen Printer Desktop Printing Machine - China

( Please click the link of the webpage bottom to view more )

This samll vacuum screen printing machine is modified on the basic of HC- 2030C mini screen printer , it have two flat choce- one is use the T- solt falt and the other is use the vaccum falt.

This machine vacuum working table is electroplated to be rust- proof, and it has the features of quick speed, steady performance , high precision, which can compose the production line in the small workshop or in samll space.

The machine especially fit for use in the vc , paper , all kinds of wood, name card, eye glass, silica gel key- press screen print and so on.

Features

1 - SCM IC coordinate light touching panel to complile action programming

2 - Adopt stainless steel cabinet to protect machine body , and its vacuum working table is electroplated to be rust- proof.

3 - Auto 4- digit counter built- in, counting printing quantity

4 - Airframe adopts coin alloy, and metal coating surface

5 - distyle vertical constructure, high precision, steady operation

6 - the transeversa stroke can be adjusted, spacing by Taiwan electronic switch

7 - the angle of scraper and ink covering blades can be adjusted randomly

8 - installing scraper constant pressure equipment to make sure pressure is steady when printing

8 - you can regulate work- table back and forth or right and left, and then fastening it

10 - you can regulate screen frame back and forth, right and left or level orientatio

11 - vacuum stainless steel worktable, it can absorb kinds of film products

12 - installing CEC oil buffer on up and down, left and righ to avoid printing shock

13 - The machine is running fastly, steably and lower noise.

14 - Action model option: fully automatic | semi- automatic | manual

15 - Start- up method: panel | foot switches

16 - scraper pressure controller: by pressure regulating Valve

17 - vertical driving style: pneumatic

Specification

1 - Mode: DY- 2030P

2 - Print area: 200x300mm

3 - Max height of printing products: 100mm

4 - transeversa stroke: 300MM

5 - vertical stroke: 160MM

6 - worktable size: 250x450mm

7 - Printing speed: 1200pcs/ hour

8 - power: 110V/ 200V 50/ 60Hz 50W

9 - Machine Size: 93x74x87CM

10 - Packing size: 104x98x84CM( L* W* H)

( Please click the link of the webpage bottom to view more )
