Lk 106mt Automatic Paper Card Hot Stamping Foil Printing Machine - China
price: contact company for price
LK 106MT Automatic Paper Card Hot Stamping Foil Printing Machine 1 - The Commercial Automatic Hot Foil Stamping Machine for Jigsaw Puzzle and Pvc Plastic Card is designed for die cutting, embossing, debossing, creasing process.
Changing mold fast, paper delivery, pull lay, paper feeding, positioning by one press, all automatic positioning will be done, together with the pressure adjustment mechanism to complete the work of cutting.
2 - Commercial Automatic Hot Foil Stamping Machine for Jigsaw Puzzle and Pvc Plastic Card by electric control, paper feeding control, paper delivery control.
3 - The Commercial Automatic Hot Foil Stamping Machine for Jigsaw Puzzle and Pvc Plastic Card is equipped with the automatic lubrication system.
MACHINE SPECIFICATIONS
Max.
sheet size
1060*770mm
Min.
sheet size
450*370mm
Max.
die cutting size
1050*750mm
Max.
stamping size
1050*750mm
Gripper margin
8-17mm
Paper Range
90 - 2000 GSM ( cardboard ) 0.1 - 2 mm ( cardboard ) lees than 4 mm (corrugated)
Max.
cutting force
300 T
Max.
mechanical speed
7500 S / H
Max.
stamping speed
6500 S / H
Foil pulling shafts
longitudinal 3
Zones individually heated
12 heating zones ( each zone can be adjusted independently, the highest adjustable temperature is 200 degree )
Max.
foil longitudinal diameter 250 mm
Max.
delivery pile height
1200mm
Max.
feeding pile height
1350mm
Main motor power
11 kw
Machine power
46 kw
Overall machine dimensions
6050*4200*2260 mm
Air requirements
0.6 MPA, more than 0.37 m³ /
Company Contact:
- Posted By: WENZHOU GUANGYA MACHINERY CO., LTD.
- Phone: +8613738750508
- Address: 258# Haize Road, Binhai New Zone, PingYang County, Wenzhou City, Zhejiang Province, Wenzhou , Zhejiang , China
- Email:
- Website: https://www.chinaguangya.com
Published date: February 2, 2018
- Business Description: Manufacturer for die cutting machine and hot foil stamping machine since 1997's
We believe " once you put your name on your equipment, forever people would remember it", CE, IEC, ISO 9001, we prepare everything that required, anyway Quality is the first core value of our company !!!
More than 20 years' time, as wide as 80 countries.
In last two decades, we have sent our machines to more than 80 countries.
Middle East, Europe, Asian, Africa, South and North America, people from various countries, language in different types, we met them and won their friendship.
With us, your money is safe, your business is safe !!!
