c om Tel: 0086 133 0311 0583 WhatsApp: 0086 133 8311 0583 Product Description The spray humidifier can be installed on the different position of the corrugator line to replenish the moisture lost in the production process, making the corrugated cardboard can maintain the appropriate moisture content - 12% to 15%.

It works well on brand corrugators.

Install Position 1)The double-sided machine sprays lining paper at the entrance to add moisture to

the lining paper before the paperboard is formed, and solves the problems of bending of the paperboard and burst lines of the lining paper.

2)Spray the inner side of the face paper (adhesive side) before the gluing machine.

Before the cardboard is formed, add moisture to the face paper to solve the problems of bending on the cardboard and bursting of the face paper.

3)Spray the face paper/lining paper before the slitter to add moisture to cardboard, completely solve the cardboard burst line and delay the cardboard storage time.

4)Single sided machine sprayed tile paper, supplement the moisture of the

corrugated paper, increase the flexibility of the corrugated paper, and prevent the corrugated paper from breaking due to drying and poor adhesion.

Features Adopting high pressure plunger pump imported from Italy for automization (no need for compressed air source), high pressure, fine atomized particles, and drip-proof nozzle.

The spray volume can be controlled by the inverter.

The control and operation power supply is a safe voltage of 24 V to ensure safe working in humid environments.

Manually and automatically switch arbitrarily, and automatically stop spraying when machine stopped.

The nozzle switch is controlled separately.
