Hot Melt Adhesive Coating Machine Controlled By Servo Motor - China

Introduction

The machine is mainly used for sanitary napkins, health

pad, baby diapers and etc.

The machine is equipped with servo

controlling system, one-piece combination fiber spraying

gun, high sensitivity rectification controller and high—

precision, sensor tension controlling system, Meanwhile,

the machine adopts thick panel

and solid structure to ensure product run smoothly in high

speed With PLC and removable touch screen console, it becomes

convenient to operate.

Application:

The machine is suitable for nonwoven, PE, breathable film

lamination, middle panel and full—width lamination of baby

diapers.

It is mainly used in the following products:

1 - Diapers for baby or adult

2 - Child training pant

3 - Sanitary napkins, Health pad

4 - Mask, operating coat, operating pad, bra pad

5 - Pet products

6 - Adult incontinence 10r~ducts

7 - other breathable products

Technical specification:

Item

Unit

YX-506

Laminating Width

mm

660

Laminating Speed

m/min

10-200

Unwinding Diameter of Nonwoven

800

Unwinding Diameter of Single-canitilever

600

Diameter of Material Receiving

High-precision Rectification

MM

±0.5

High-precision Tension

N/m

Machine Dimension: L/W/H

5000/2000/1900

Features:

1 - The machine working time will be improved greatly with

high strength panel structure and the stability of whole

machine

2 - With double position design one time of lamination could

achieve twice finished products that could maximize the

value of the realization of the machine.

3 - Hidden type high precision tension control unit, precise

calculation of servo motor d riving synchronous control

winding speed.

4 - With rectification controller and high-performance electro

—optical sensor.

it could ensu re the material in order

5 - It could slow down automatically when the material is

less

6 - The material could be kept it well when we shut down the

7 - Removable touch screen console.

flexible and convenient

operation.

8 - The machine has function of acceleration—setting and

deceleration—setting .

9 - The length of product could be set according to

customer’s requirements

10 - Malfunction of the equipment could be found in short

time with malfunction display function

11 - G ram weight of the glue in everywhere could also keep

same when the speed is changing

12 - using sophisticated technology manufacturing sizing

device, ensure the sizing precision and stability

13 - Coating spray gun is equipped with automatic closing

glue device
