Computer Spiral Crosscutting Machine - China

Huatao Group - Corrugator Belt & Spare Parts

www(dot)htwirebelt.

com sandy(at)huataogroup.

com Tel: 0086 133 8311 0583 WhatsApp: 0086 133 8311 0583 NC cut off machine vailable breadth: 1400-2200mm Specification: 1 - Max machine speed: 200m/min, when cutting length is 0.5m speed is 100m/min 2 - Cutting length: 500mm-9999mm, cutting accuracy±1mm 3 - Up to 999 job size can be preset, auto change job size without machine stop, connected with the computer to make production management easy 4 - All drive gear made of high quality alloy steel, which are heat treated and exactitude processed, high drive accuracy and long life 5 - Circulating lubrication to insure lubricate and also help to clean and cool 6 - Paper entering and out are separated, each have their frequency convert motor to control speed, synchronized driven, stable and low noise 7 - Double-row round wheels are used at entrance to reduce the cutting errors caused by dithering of paper board.

8 - Exit and sending platform use round wheels and conveyer belt, which make paper board ejection steady.

9 - Round wheels device pneumatic controlled, special design, easy to operate 10 - Pedestal and wheel box made of grey cast iron, good steel and good shake-resistance 11 - AC servo-control system energy save above 30% 12 - Motor main motor: 37kw/55kw oil pump motor: 0.2kw convey motor: 2.2kw WIDTH(MM) DIMENSION (L X W X H)(MM) WEIGHT(T) GROSS POWER(KW)

1400 2380×2220×1250 6 37

1600 2580×2220×1250 6.5 37

1800 2780×2220×1250 7 55

2000 2980×2220×1250 7.5 55

2200 3180×2220×1250 8 75
