Tube Sheet Drilling Machine Thd50 - China

THD50 Movable Gantry High Speed CNC Drilling Machine for

flanges, tube sheets, and plates

1 - Special machine for drilling flange & plates, Max.

flange diameter Ø5000mm

2 - Inner water cooling spindles imported from Taiwan

3 - Auto chips removal, auto clamping & loosening for

flanges by the patent know- how

4 - AC contactor, switch from Mitsubishi, Japan; Servo

motor, Servo pack from Yaskava; relay from IDEC, Japan; CNC

system Siemens, Germany; bearing NSK, Japan

5 - Rotary working- table with high rigidity, higher &

reliable precision

6 - No vibration in drilling by the patent know- how

7 - Drill bit wearing monitoring system by the patent know-

how

8 - Auto lubrications

Machine Model THD50

Flange size Outer diameter scope mm Ø5000

Max.

thickness mm 250

Drilling spindles Rotation speed rpm 50- 3000

Power KW 30

Stroke mm 500

Quantity Pc.

2

Max.

drilling diameter mm Ø50, drilling Ø80 &

Ø120mm as option

Drill bit type Pc.

Inner water cooling

Precision Drilling precision mm ±0.1

Positioning precision mm ±0.06

Repeat position precision mm ±0.03

CNC axis Quantity Pc.

4

X axis feeding mm/ min.

0- 8000

Y axis feeding mm/ min.

0- 8000

Z axis feeding mm/ min.

0- 5000

Z axis work feeding mm/ min.

0- 200

Total power KW 90

Weight KG Appr.

75000

Dimensions ( L×W×H) mm 8500×8000×3500

1 - Germany machines' quality, China machines' price

2 - Two drilling spindles make this machine to be equal to 2 CNC

machines

3 - High speed drilling to make the good hole surface and

precision

4 - Special and professional designing for flange drilling

5 - All flanges can be drilled

6 - Auto clamping and auto loosening, and auto chips removal

7 - If operations are good and keep the good maintenance, the

machine shall not happen any problems within many years; this

is the feedback from our customer

8 - If you buy one set of our machines, I shall tell me you

shall like this machine and buy more and more such kinds of

this machine, because it is very convenient and real Germany

machine quality.

1 - One machine is equal to 2 sets of CNC high speed flange and

tube sheet drilling machine

2 - Auto clamping and auto loosening

3 - Highest flange drilling efficiency

4 - Highest precision for flange drilling

5 - Stable and reliable machine quality, TECH from Germany

6 - Special machine for flange drilling, save more labor cost

7 - Early buy, early getting more benefits

ZL 2013 2 0377083.7

ZL 2013 2 0746931.7

ZL 2013 2 0747230.5

ZL 2013 2 0746891.6

ZL 2013 2 0747222.0

ZL 2013 2 0746750.4

ZL 2013 2 0751414.9

ZL 2013 2 0005499.6
