Charcoal Powder Briquette Machine - China

Charcoal powder briquette machine is a series of charcoal briquette machine equipment with the technical content of equipment.

Using the principle of screw extrusion, the prepared powder charcoal is compressed into a briquette making machine with a certain strength and predetermined shape.

Charcoal Powder Briquette Machine Introduction

Charcoal powder briquette machine also called briquette making machine, mainly includes frame, bearing, screw axis, barrel outlet, and charcoal briquettes of mold, charcoal briquette machine is using the principle of screw extrusion, the prepared a charcoal powder into charcoal briquettes have a certain intensity, is widely used in coal, coal, coal gangue, coking coal, lignite, anthracite coal, iron powder, aluminum powder as raw materials to make briquette.

Using a charcoal powder briquette machine to make briquette can fully use charcoal powder, in the process of production does not need to add lime, reduce the cost of fuel, and improve the calorific value of coal, with high economic benefits.

Charcoal Powder Briquette Machine Features

1 - The outlet is lined with a wear-resistant sleeve and a charcoal mold, which is blocked by the nut at the outlet end.

2 - The pitch of the spiral blade of the spiral axis gradually decreases from right to left.

There is a dirt baffle between the charcoal briquette machine barrel body and the bearing seat, and an oil seal side.

There is a sewage outlet on the barrel body between the dirt baffle and the dirt baffle plate.

3 - The inner wall of the wear-resistant sleeve of the charcoal briquette machine barrel body has a number of anti-wear grooves, and the anti-wear grooves are not connected by one end of the discharge port.

4 - The charcoal mold center of the briquette making machine has a convex guide.

5 - Charcoal powder machine wear-resistant sleeve and screw shaft blade friction surface spray with hard alloy powder.

Working Principle Of The Charcoal Powder Briquette Machine

Charcoal powder briquette machine is a machine to make different shapes of raw coal into bars.

The motor passes the power to the transmission through the triangle belt, the transmission output shaft passes the power to the propulsion shaft through the floating coupling, and the propeller on the propulsion shaft pushes the coal through the molding die head to produce the ideal high-pressure coal bar.

Advantages Of Charcoal Powder Briquette Machine

Advantage 1: Various styles

Mold patterns have plum blossom, triangle, quadrilateral, diamond, and other styles, can be customized according to customer requirements.

Advantage 2: Good finished product with high strength

Stable operation, low noise, small wear, long life.

High output, low energy consumption, high performance-to-price ratio, high finished product strength.

Advantage 3: Good steel quality

Improve the service life of the whole machine, easy to repair, reduce consumption, safe and reliable operation, quality assurance.

Advantage 4: Accessory alloy reamer

The fittings of briquette making machine are reamer, the reamer is made of alloy, wear-resistant, durable, efficient and energy-saving, widely used.

The mechanical equipment of Fusmar sells well in domestic and foreign markets and enjoys a high welcome among consumers.

With years of hard work, Zhengzhou Fusmar has established a complete and effective service system and built an experienced service team.

We will carry out after-sales tracking service for the charcoal briquette machine equipment sold.
