Low Noise Big Industrial Ceiling Fan For Ventilation - China

Product introduction

The wind generated by Dawang industrial fans provided for this project is similar to the natural breeze system, It's the wind speed that your skin feels best when it's cool .

The body can feel the temperature difference of 5-8 degrees, they can have a comfortable working environment in hot summer, improving production efficiency.

"Healthy-wind" series industrial large ceiling fans maximum diameter can reach 7.3m, hung on the rooftop.

Similar to regular small ceiling fans, but different from small ceiling fans, they can generate large air flow at low speed, form cross-ventilation through the whole building, to realize ventilation and cooling.

Work principle

After years of dedicated research and exploration, Dawangfans integrates foreign advanced aviation technology to develop superior performance propeller fan blade, only need rotating slowly form a continuous and quiet breeze sir.

The slow rotation of uniquely efficient airfoil-shaped blades creates large airflow pushing down, thus forming a perfect exhaust of propeller blade.

Large airflow pushed to the ground, forming air layer horizontal movement at a certain height on the ground to promote the whole air circulation.

The advantage is full coverage of the ground and three-dimensional circulation of the air.

Product parameters

1 - Coverage: ≥1400 ㎡

2 - Body feeling temperature reduction: 5-7℃

3 - Power supply: 380V/220V 50Hz, 1.5KW

4 - Blade qty/material: 5pcs, aluminum sheet model AL5052H32

5 - Blade layer/thickness：double 1.5mm aluminum alloy plate *5pcs

6 - Blade surface: Blades, wheel chassis and other parts are required to water-proof and air corrosion

7 - Noise: ≤60dba 8 - Motor brand: German Nord

9 - Speed controller: TOCOS/RV24

10 - wheel chassis material: AL6061-T6(mortise and tenon joint structure)

11 - Blade color: sliver(Aluminum original color) 12 - Control system: schneider frequency converter + schneider interrupter

13 - Consumption：≤0 - 8KWH 14 - Own patent: inner cone, wheel chassis structure, blade and wheel connection, appearance Jiangsu Dawang Ventilation Machinery Co., Ltd
