Xy 2 Diamond Core Drilling Machine - China

Specifications

it is small and light weighted, mainly used in shallow and

medium deep diamond tungsten carbide core drilling

XY- 2 DRILLING MACHINE

XY- 2 hydraulic feed core drill is small and light weighted,

mainly used in shallow and medium deep diamond tungsten

carbide core drilling, can also be used in engineering

geological, hydrogeological, water well and pile grouting

hole drilling

Technical Specifications

Drilling capacity( m) 73 rod 100

60 rod 200

50 rod 380

42 rod 530

Spindle speed( r/ min)

Forward 65; 114; 180; 248;

310; 538; 849; 1172

Reverse 51; 242

Max torque ( Nm) 2760

Angle reange 0- 90°

Spindle max pull force( KN) 60

Spindle stroke ( mm) 600

Hoist max life capacity with single rope ( KN) 30

Spindle inner dia ( mm) 76

Oil pump SCB32/ 12

Power unit Electric motor Y180L- 4, 22Kw

Diesel engine 395K2, 19.85Kw

Inner dia of spindle ( mm) 2150×900×1690

Drill body weight ( excluding power) ( kg) 950
