    • Eccentric Overburden Casing System Drilling Tools For Sale - China

    price: 500.00 Dollar US$

    Eccentric Overburden Casing System Drilling Tools For Sale

    Products Photos Catalog Eccentric Overburden Photos Catalog

    Eccentric Drilling Tools with Casing Tube Eccentric is the most economical solutions because its ingenious reaming wing the bit is retrievable can be used at the next hole.

    This is particularly design for shallow holes, as is often the case in water well drilling, geothermal wells and for shallow micro-piling work.

    Odex is ideal for short holes in consolidated overburden.

    Eccentric Drilling Tools with casing tube step-by-step:

    1 - When drilling, the PGZ(Eccentric Drilling Tools) reamer swings out and drills a hole wide enough for the casing tube to slide down behind the reamer.

    2 - When required depth is reached, the dill is reversed and the reamer swings in, allowing the bit to pass through the casing.

    3 - Casing tube is pulled out directly or fixed at the bottom of the hole by means of cement grout or other ragglutinant.

    4 - Drilling continues to the desired depth using conventional DTH equipment.

    3'' PGZ82-3.5-108/6: shank for TND-IR3.5 / DHD3.5 / TD3.5 hammer PGZ90-3.5-114/6: shank for TND-IR3.5 / DHD3.5 / TD3.5 hammer

    4'' PGZ115-340-142/7: shank for TND-IR340 / DHD340A / TD4 hammer PGZ115-340-146/8: shank for TND-IR340 / DHD340A / TD4 hammer

    5'' PGZ140-350-168/8: shank for TND-IR350 / DHD350R / DHD5 hammer PGZ145-350-178/9: shank for TND-IR350 / DHD350R / DHD5 hammer PGZ147-350-183/10: shank for TND-IR350 / DHD350R / DHD5 hammer

    6'' PGZ165-360-195/6.5: shank for TND-IR360 / DHD360 / COP64 / DHD6 hammer PGZ180-360-219/12.5: shank for TND-IR360 / DHD360 / COP64 / DHD6 hammer PGZ190-360-219/7: shank for TND-IR360 / DHD360 / COP64 / DHD6 hammer

    8'' PGZ230-380-273/11.5: shank for TND-IR380 / DHD380 / COP84 / DHD8 hammer PGZ240-380-273/6.5: shank for TND-IR380 / DHD380 / COP84 / DHD8 hammer


    Company Contact:


    • Phone: +867176343815

    • Address: Wujiagang Industrial Park, Yichang , Hubei , China

    • Email: Email


    Published date: October 27, 2017 - Modified date: November 9, 2017

    • Business Description: Our factory mainly manufacture and supply global buyers a variety of high, medium and low air pressure dth hammers and bits, API thread drill pipes, eccentric and symmetric casing systems, and hydraulic top hammers including tapered button bits, coupling sleeves and shank adapters with high quality.

      Our products are also perfectly compatible with the famous brands such as Atlas Copco, Ingersoll-Rand, and other well-known manufacturers with high durability and long working life.
