Pvc And Pvg Conveyor Belt - China

PVC & PVG Conveyor Belt core flame retardant conveyor belt reinforced rubber belting PRODUCT DESCRIPTION

Baoxiang PVG Conveyor Belt Specification

Type Tensile strength/ N/mm, ≥ Breaking elongation/ %, ≥ Top/bottom cover/mm, ≥ Longitudinal Transversal Longitudinal Transversal 680S 680 265 15 18 1.5

800S 800 280 1000S 1000 300 1250S 1250 350 1400S 1400 350 1600S 1600 400 1800S 1800 400 2000S 2000 400 2240S 2240 450 2500S 2500 450 PVC Conveyor Belt

Specification

Type Tensile strength/ N/mm, ≥ Breaking elongation/ %, ≥ Top/bottom cover/mm, ≥ Longitudinal Transversal Longitudinal Transversal 680S 680 265 15 18 1.0

800S 800 280 1000S 1000 300 1250S 1250 350 1400S 1400 350 1600S 1600 400 1800S 1800 400 2000S 2000 400 2240S 2240 450 2500S 2500 450 Safety performance

Name of the performance Alcohol burning Propane burning Different electric performance Roller friction

Standard value Average value≤3S, single value≤10S (with cover glue) ≧250mm ≦3x10 8 Ω ≦325°C Average value≤5S, single value≤15S (with cover glue) No mars The whole core flame retardant conveyor belt is made of the whole belt core impregnated by PVC impregnated paste plasticization or vulcanization, with large strength, large volume, transport balance and other characteristics, and the product has good flame retardant, antistatic, impact resistance, wear resistance, corrosion resistance and other properties.

The whole core flame retardant conveyor belt is mainly used in underground coal mine, but also for material transportation in metallurgical and chemical industries.

The belt features: no delamination, small elongation, impact resistance, tear resistance.

According g to the different knots can be divided into PVC type (plastic surface), PVG type (on the basis of PVC with rubber surface) whole core flame retardant tape.

PVC upper and lower covering layers shall be PVC cover adhesive, single side adhesive ≥ 0.8mm, PVG upper and lower covering layers shall be both nitrile butadiene rubber and PVC, and the single thickness shall be 1.5mm-4.5mm

PVC conveyor belt transport dip Angle <16°, PVG conveyor belt transport dip Angle <20°, can be used in coal mines, underground transport.

Baoxiang is a multifunctional conveyor belt manufacturers that integrates production line development, manufacturing, debugging and technical transformation.

Its products include conveyor belting, nylon conveyor belt, etc.

Company Contact:

• Posted By: Hebei Baoxiang Conveyor Belt Manufacturing Co.,Ltd

• Phone: 8603128718777

• Address: Liutuodian Village,Boye County, Baoding , Hebei , China

• Email:

• Business Description: Hebei Baoxiang Conveyor belt Manufacturing Co., Ltd. Is a medium-sized joint-stock enterprise leading in the production of "Baoxiang" special series conveyor belt, located in The Industrial zone of Liutuodian, Boye County, Hebei Province.

  Founded in 2010, it is a key enterprise of chemical industry in Hebei Province and a member of China Rubber Industry Association.

  Main production B6000mm under ordinary conveyor belt, nylon, polyester, raised edge conveyor belt conveyor belt, heat resistant, high temperature resistant conveyor belt, or circular conveyor belt, pattern conveyor belt (herringbone pattern, concave and convex decorative pattern, eight decorative pattern, fishbone, u-shaped pattern, cylindrical pattern, pitting pattern conveyor belt, etc.

  ), PVC, PVG entire core flame retardant conveyor belt, acid and alkali resistant, oil resistant conveyor belt conveyor belt, steel wire laceration resistant conveyor belt, round tubular conveyor belt, rubber hose, spiral mesh conveyor belt, etc.

  The processing workshop is equipped with large and small cars, washing planing and drilling machine and other equipment.

  The main products are TD75 type, DTII type, dX type, DY type mobile type and other types of conveyors, inverters, shaft connectors, sweepers, roller series, bracket series and idler series.

  The company has complete testing facilities, with independent chemical analysis room, physical laboratory, raw materials and semi-finished products, finished products are under control.

  Our company always insists on winning by innovation, optimizing product structure, strengthening basic management, expanding market and enhancing enterprise vitality.

  Only to provide quality products and perfect service, is the best return to customers.
