Material Handling Conveyor Belt - China

Acid-alkali Resistant Conveyor Belt conveyor belt wholesaler material handling conveyor belt Baoxiang Acid and alkali resistant conveyor belt is a kind of working environment suitable for contact with acid and alkali.

It is blended with rubber and plastic and filled with inert materials with excellent acid and alkali resistance.

PRODUCT DESCRIPTION

Acid-alkali Resistant Properties of Rubber Cover, Conveyor Belt Wholesaler

Class Soak liquid Concentration Soak conditions(℃×h) Change rate of properties before and after soaking Volume expansion rate Change rate of tensile strength

A1 Hydrochloric acid (HCl) 18% 50℃×96h ≤+10% ≥-10%

A2 Sulfuric acid(H2SO4) 50% 50℃×96h ≤+10% ≥-10%

A3 Sodium hydroxide(NaOH) 48% 50℃×96h ≤+10% ≥-10% Full-thickness tensile propertiesa.

a.

Full thickness, longitudinal tensile strength after-aging test reduces not lower than 30% of before-aging values.

b.

Full thickness, longitudinal elongation at reference force, not more than 4%.

c.

Longitudinal tensile strength, not less than the below table.

(N/mm) Nominal belt type 160 200 250 315 400 500 630 800 1000 1250 1600 2000 2500 3150 Ply adhesion at normal temperature

Item Ply to ply Rubber cover to ply

All samples average value/ (N/mm) ≥ 4.5 3.5

All samples min peak value/ (N/mm) ≥ 3.9 2.9 Covered with rubber Index name Index Hardness(shor A)degree 55±5 Abrasion value/1.6cm, ≤ 1.20 Tensile strength Mpa≥ 12.0 elongation at break %≤ 400 Acid resistance coefficient：(15-25℃, 24h40%H 2 SO 4 ) ≥0.8

Through thickness Adhesive strength of tape and cloth Rubber cover＞1.5mm

rubber cover≤1.5mm ≥3.2N/mm

≥2.8N/mm Interlaminar (longitudinal mean) bonding strength of adhesive tape ≥3.2N/mm Elongation at break (total) ≥10% Acid And Alkali Resistant Conveyor Belt Features: cotton canvas, nylon canvas or polyester canvas as the core, with good elasticity, good groove performance and low elongation.

The coating adhesive made of acid-alkali resistant material has good chemical resistance and physical properties.

Application: Suitable for conveying corrosive materials containing acid in a chemical plant, chemical fertilizer plant, paper mill, etc.

Acid and alkali resistant conveyor belt (acid and alkali resistant conveyor belt) is suitable for a working environment in contact with acid and alkali, such as phosphate fertilizer manufacturing, seawater salt.

An acid-alkali resistant conveyor belt (acid-alkali resistant conveyor belt) covering adhesive is made of rubber and plastic mixed and filled with material with excellent alkaline nature, which is better than neoprene in the acid-alkali resistant conveyor belt.

The skeleton material adopts polyester canvas, which is more reliable than cotton canvas core belt in resisting acid and alkaline.

Baoxiang is a multifunctional conveyor belt manufacturers that integrates production line development, manufacturing, debugging and technical transformation.

Its products include conveyor belting, nylon conveyor belt, etc.

Company Contact:

• Posted By: Hebei Baoxiang Conveyor Belt Manufacturing Co.,Ltd

• Phone: 8603128718777

• Address: Liutuodian Village,Boye County, Baoding , Hebei , China

• Email:

• Business Description: Hebei Baoxiang Conveyor belt Manufacturing Co., Ltd. Is a medium-sized joint-stock enterprise leading in the production of "Baoxiang" special series conveyor belt, located in The Industrial zone of Liutuodian, Boye County, Hebei Province.

  Founded in 2010, it is a key enterprise of chemical industry in Hebei Province and a member of China Rubber Industry Association.

  Main production B6000mm under ordinary conveyor belt, nylon, polyester, raised edge conveyor belt conveyor belt, heat resistant, high temperature resistant conveyor belt, or circular conveyor belt, pattern conveyor belt (herringbone pattern, concave and convex decorative pattern, eight decorative pattern, fishbone, u-shaped pattern, cylindrical pattern, pitting pattern conveyor belt, etc.

  ), PVC, PVG entire core flame retardant conveyor belt, acid and alkali resistant, oil resistant conveyor belt conveyor belt, steel wire laceration resistant conveyor belt, round tubular conveyor belt, rubber hose, spiral mesh conveyor belt, etc.

  The processing workshop is equipped with large and small cars, washing planing and drilling machine and other equipment.

  The main products are TD75 type, DTII type, dX type, DY type mobile type and other types of conveyors, inverters, shaft connectors, sweepers, roller series, bracket series and idler series.

  The company has complete testing facilities, with independent chemical analysis room, physical laboratory, raw materials and semi-finished products, finished products are under control.

  Our company always insists on winning by innovation, optimizing product structure, strengthening basic management, expanding market and enhancing enterprise vitality.

  Only to provide quality products and perfect service, is the best return to customers.
