Top Entry Trunnion Mounted Ball Valve Supplier - China

Top Entry Trunnion Mounted Ball Valve

The Top Entry Trunnion Mounted Ball Valve is a high-performance industrial valve designed for use in a wide range of applications.

It features a trunnion-mounted ball design that allows for smooth and efficient flow control, making it ideal for use in pipelines, process plants, and other heavy-duty industrial environments.

The valve's top-entry design allows for easy maintenance and repair, while its robust construction ensures long-lasting durability and reliability.

With features such as a flexible and reliable seal, low operating torque, and a wide range of sizes and pressure ratings, the Top Entry Trunnion Mounted Ball Valve is a versatile and dependable choice for any industrial application.

The connection ends can be flange or butt welding.

The valve trims have been carefully designed and selected to ensure reliability under various service conditions.

Top Enry ball valves are more often required in the Trunnion version But it is possible to supply also the floating one.

DBB(double Block and bleed) design can be supplied upon request.

We are a professional valve company, have high quality ball valve, contact us to buy online.

Product Range

1 - Pressure range: CLASS 150Lb~2500Lb

2 - Nominal diameter: NPS 2~60″

3 - Body material: Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy

4 - End connection: RF RTJ BW

5 - Working temperature: -29℃~350℃

6 - Mode of operation: Lever, Gear box, Electric, Pneumatic, hydraulic device, Pneumatic-hydraulic device.

7 - Design standard: API 6D API 608 ISO 17292.

Product Features

1 - On-site maintenance

2 - Soft or Metal sealing

3 - Integral structure

4 - Single piston effect

5 - Double block and bleed

6 - Extended stem design

7 - Anti- static design

8 - Fire safe design

9 - Zero leakage

Advantages

Some advantages of the Top Entry Trunnion Mounted Ball Valve include

1 - Easy maintenance and repair due to its top-entry design

2 - Smooth and efficient flow control due to its trunnion-mounted ball design

3 - Low operating torque which reduces the need for heavy actuators

4 - Durable and reliable construction, suitable for heavy-duty industrial use

5 - A flexible and reliable seal that provides a tight shut-off

6 - Available in a wide range of sizes and pressure ratings to meet different application needs

7 - Potential reduced downtime due to its design

8 - Variety of materials of construction like carbon steel, stainless steel, alloy steel etc to suit different application and process conditions.

Application

The Top Entry Trunnion Mounted Ball Valve is well suited for a variety of industrial applications, including:

1 - Pipeline systems: The valve's efficient flow control and durable construction make it well suited for use in pipeline systems that transport liquids, gases, and other materials.

2 - Process plants: The valve's reliable seal and low operating torque make it ideal for use in process plants, where it can be used to control the flow of chemicals, fuels, and other industrial fluids.

3 - Oil and gas: The valve's durability and resistance to harsh environments make it suitable for use in oil and gas production facilities, as well as in offshore platforms and subsea pipelines.

4 - Power generation: The valve is often used in power generation plants, including nuclear, coal, gas, and renewable energy facilities, to control the flow of coolants, fuels, and other critical fluids.

5 - Pharmaceutical, Food and Beverage and other hygienic process industries: the valve is well suited for use in these hygienic process industry, where the valve need to be designed to meet the stringent standards of hygiene and cleanliness.

These are just a few examples, Top Entry Trunnion Mounted Ball Valves can be used in many other industrial settings where flow control is needed.

We look forward to working with you!

Toparts Valve Co., Ltd is located in Bihu Town, Lishui City, Zhejiang Province.

It is a valve manufacturer integrating R&D, production and sales.

With the support of various large and medium-sized advanced equipment such as CNC vertical lathe, vertical machining center and horizontal machining center, it has built a mature and effective operation mechanism from product R&D to overall product quality control.

We provide the highest quality valves with long service life.

We have an independent factory, can provide agent processing services! If you are interested in our products, welcome to contact us!
