Side Entry Trunnion Mounted Ball Valve

Trunnion mounted ball valve is a new generation of high-performance ball valve, suitable for long distance pipelines and general industrial pipelines.

Designation takes full consideration to its strength, safety, resistant to harsh environments, so it can apply to a variety of corrosive and non-corrosive media.

It is used to cut off or connect the media in various pipelines of Class 150~Class 2500 - The Side Entry Trunnion Mounted Ball Valve is a type of industrial valve that is designed for use in high pressure and high temperature applications.

It features a trunnion design that allows for secure and stable operation, with the ball being supported at two points (top and bottom) which ensure that it does not rotate or move out of place.

The side entry design allows for easy maintenance and servicing, as the valve can be accessed from the side without the need to remove any pipework.

The valve is made of durable materials such as carbon steel or stainless steel, which makes it suitable for use in demanding environments.

It is available in a variety of sizes and pressure ratings, and can be actuated manually or with an automated system.

This type of valves are widely used in Oil & gas and chemical industry.

The valves are made of different materials, which are suitable for various media such as water, oil, liquefied gas, natural gas, etc.

The double piston effect design (available on request), maintains the sealing capacity of the valve even in the case of failure of the up stream seats, Bodg cavity over pressure in this case can be released through a relief valve to atmosphere.

The tightness is assured by the piston effect acting on the seat, pressing it against the ball, once the valve is pressurized.

Buy Ball Valve and get high quality side entry trunnion mounted ball valve at a good price, contact us to know more.

Product Range

1 - Pressure range: CLASS 150Lb~2500Lb.

2 - Nominal diameter: NPS 2~60″.

3 - Body material: Carbon steel, Stainless steel, duplex stainless steel, Alloy steel, Nickel alloy.

4 - End connection: RF RTJ BW.

5 - Mode of operation: Lever, Gear box, Electric, Pneumatic, hydraulic device, Pneumatic-hydraulic device.

6 - Design standard: API 6D ISO 17292 - Product Features

1 - Side entry

2 - Full bore / Reduce bore

3 - Double block and bleed

4 - Blowout- proof stem

5 - Anti-static design

6 - Fire safe design

7 - Sealant injection at seat and stem

8 - Zero leakage The main advantages of the Side Entry Trunnion Mounted Ball Valve include

1 - High pressure and high temperature capability: The trunnion design and durable materials make the valve suitable for use in high pressure and high temperature applications.

2 - Stable and secure operation: The trunnion design provides stability and prevents the ball from rotating or moving out of place, ensuring safe and reliable operation.

3 - Easy maintenance and servicing: The side entry design allows for easy access to the valve's internals, making maintenance and servicing more convenient.

4 - Variety of sizes and pressure ratings: The valve is available in a range of sizes and pressure ratings, making it suitable for a wide range of applications.

5 - Can be actuated manually or with automated systems: The valve can be operated manually or with an automated system, providing flexibility in terms of control and operation.

6 - Widely used in demanding industry: The durability and reliable features make it widely used in Oil & gas and chemical industry where high pressure and high temperature is require to handle.
