Lz Type Flexible Pin Coupling China - China

LZ Type Flexible Pin Coupling

Flexible Pin Coupling

· Model: LZ Type

· Norminal Torque: 0.112kN.

M - 2800kN.

M

· Allowed Rotation Sppeed: 5000rpm - 460rpm

· Connection: Shaft hole

· Shaft Hole Diameter(d1, d2, dz): 12mm - 850mm

· Shaft Hole Length (L): 27mm - 880mm

· Applications: Metallurgy, mining, lifting, transportation, petroleum, chemical, ships, textile, light industry, agricultural machinery, printing machines and pumps, fans, compressors, machine tools and other mechanical equipment and industry shaft transmission.

LZ type flexible pin drum gear coupling's outer edges of the two half-couplings and the inner edges of the outer sleeve are made into semi-circular grooves with the same radius, which are combined into the pin holes to embed the pins.

The half-coupling of the driving shaft drives the outer sleeve through the pins, the outer sleeve drives the driven half-coupling to rotate by the pins to transmit the torque.

Working temperature: -20 ~ +70 ℃
