Vertical Alloy Wheel Repair Lathe Ckl35 - China

Quick Details

Condition:

New

Type:

Vertical

CNC or Not:

CNC

Automatic Grade:

Automatic

Max.

Swing Diameter:

1000mm

Place of Origin:

Shandong, China (Mainland)

Brand Name:

HAISHU

Voltage:

380v 50hz

Power(W):

5.5KW

Dimension(L*W*H):

2000*1550*2000

Weight:

1500kg

Certification:

CE SGS

After-sales Service Provided:

Engineers available to service machinery overseas

Name:

vertical alloy wheel repair lathe CKL35

Color:

White

Machine Type:

wheel rims repair

Function:

Wheel Rim Repair

Warranty:

12 Months

Control system:

HAISHU

Product type:

Alloy Wheel Refurbishment

Spindle speed:

50-1200

Max.

turning diameter:

1000mm

Precision:

High Precision Machine vertical alloy wheel repair lathe CKL35 is designed and manufactured by Haishu Machinery, it is the first cnc vertical cnc lathe special for repair wheels in China.

Our vertical wheel repair lathe CKL-35 is made of fully cast iron lathe bed, self developed specific wheel repair software with teaching and curve automatic generation function, non-contact laser measurement or probe contact measurement an LCD touch screen.

The max wheel processing diameter is up to 35 “.

The CNC wheel repair machine features professionalism, high quality, cost effective and high automation.

vertical alloy wheel repair lathe CKL35 Features ·Newly developed Vertical Wheel Repair Lathe by HAISHU Machinery for alloy car wheel repair and super finishing.

·Cast iron bed.

The wheel repair CNC lathe bed is made of cast steel in vertical structure.

·Large wheel processing diameter.

The max wheel processing diameter is up to 35 “.

·Self-developed special wheel repair control software.

Automatic wheel surface measurement and program optimization can be realized simultaneously.

·Laser non-contact measurement or probe contact measurement are optional.

Laser measurement enables fast scanning.

·Teaching function.

The overall wheel surface of can be repaired, but also can be partially repaired.

·LCD touch screen configuration ·Compared with the horizontal structure, the mechanical transmission is more stable, the turning performance is better and the machining precision is higher.

·Small machine tool space, professional CNC lathe for wheel repair.

·Professional after sale service including software free upgrade and remote operation and technical training on the machine’s LCD display.

·High performance, cost effective.

·Easy to operate and maintain.

vertical alloy wheel repair lathe CKL35 Configurations · CNC system: “HAISHU” LCD touch screen CNC system · Laser probe · Precision spindle unit · Z-axis dual servo motor drive · X, Z axis linear guide · Precision screw vice · Software and hardware limit · Rail protection system · Automatic lubrication system · Air cooling system · Air gun · MPG · Warning lights · Full protection outer casing · Chip removal box · Pneumatic door · Long jaw chuck · 2 Station row turret · Z safety brake · Automatich pneumatic door
