Plasma Cutting Machine - China

Machine Feature:

1 - The machine adopts the host system (computer host) produced by Sino-US joint venture, the transmission rail made in Taiwan, the gas solenoid valve of Italy origin, approved by the United States UL

Taiwan switching power supply, German nesting software, all hardware and software are the best configuration of similar products.

2, the operation is simple and convenient and can improve the utilization rate of steel: not only can the simple graphics directly manual programming on the system host video, but also can be randomly presented by the nesting software for any complex graphics automatic nesting programming.

Using nesting software can not only carry out the conventional single workpiece cutting but also can be very convenient for multiple workpiece coedge arrangement nesting cutting, series and bridging cutting (one-size-all).

Can improve the steel utilization rate of 1-5 percentage points.

3, large program storage capacity: users can according to the need to store 1000 pieces of cutting workpiece drawings, at any time to call the storage drawings for the workpiece cutting operation, save the trouble of drawing and input drawing repeatedly.

4, high cutting accuracy: cutting 500mm x 500mm square workpiece diagonal length and the diagonal length of the drawing error ≤ 1mm.

Cutting section roughness reaches, cutting back does not produce slags.

5 - Plasma arc cutting and gas flame cutting can be selected according to customer needs.

When plasma cutting is selected, the machine is equipped with automatic arc pressure adjusting system and initial arc positioning device to ensure continuous arc in the cutting process, and to ensure that the arc is 100% stable when plasma cutting begins.

6 - The lifting system of the cutting torch (cutting gun) adopts the mechanical structure of the screw rod and is equipped with the anti-cutting gun bump device to ensure the stable operation of the cutting gun and avoid the damage caused by the collision of the cutting gun.

7, the base adopts the whole steel annealing treatment, precision machining molding, to ensure stable and reliable operation
