Die Casting Mold Manufactory - China

Aluminum die cast with precision machining die casting mold manufactory custom pressure aluminum casting Good machining fixture design will provide high efficiency and guaranteed strict tolerances at same time.

How many pieces on one machining fixture? We suggest put six or eight parts when your parts size from 6CM-12CM.

clamping by air cylinder is tight enough.

Some die casting producer in china still clamping parts by screwing, this is low production efficiency.

Products will deformation if screwing to tight, cutting knife will broken when screwing bit loose.

Perfect machining fixture designer will take into consideration many facts.

For example how to make machining operator put in and take out much convenient.

Which part on casting parts fit for clamping, many part on casting body not fit for clamping, such as thin wall, surface with casting die joint, surface with air vent, surface with protrude ejector pin.

Looking thick wall and flat part for clamping is right chose .

Many die casting tooling supplier forget indicate the draft angle for machining workshop.

it will make seriously mistake during machining fixture design.

This is why aluminum die casting mould manufactory should provide all details information on DFM Machining scrap wipe off by air gun should high frequency, any scrap remain on fixture will damage parts surface, also will impact tolerances.

Why some aluminum scrap stick on machining fixture so tight? Because cooling lubrication to sticky.

To find right cooling lubrication is more important looking powerful air gun.

Many die casting manufactory in china select wrong cooling lubrication, some to sticky, some to watery.

Machines custom design to meet specially machining request.

CNC machines customization is very popularly in custom pressure aluminum casting industry.

Particularly for large quantity products machining.

Discuss between aluminum injection molds team and machining department at soon When we get inquiry from customer.

ten years before the big project from auto industry attached us, but price almost no any profit.

We drilling hole by brother CNC drilling and milling recombination machining center.

The brother CNC drilling and milling recombination machines have good reputation for their fast production among the aluminum die casting factory.

But the production capability still limited.

1.5cm diameter, depth 7.5 cost almost 2 minutes.

Assemble line in customer factory was very anxiety for our production capability.

We purchased the custom made deep hole drilling machines from Mitsubishi after urgency meeting.

2 minutes drill 5 deep holes.

The tolerances control much strict compare the machining center.

This is great enhanced production capability.

Now the Mitsubishi deep hole machines have very good reputation among china aluminum die casting man.

Company Contact:

• Posted By: Ningo Goal Sure Machining Co. ,Ltd

• Phone: 86057483017530

• Address: Dong Qiao Zhen Bai Liang Qiao Cun, Haishu District, Ningbo , Anhui Sheng, China

• Email:

• Website: https://www.gsdiecasting.com/

• Business Description: Ningo goal sure machining co.

  ,ltd was founded in 2001, located aluminum die casting mold hometown Ningbo.

  Year 2007 company total investment 50million yuan, on 30 acre land build up 2000 square meters pressure die casting mold workshop, 3500 square meters pressure aluminum casting products workshop, 600 square meters aluminum die casting tools accessories workshop.

  The factory has more than 20 senior technical staff engaged in pressure aluminum die casting industry many years.

  we use most advanced simulation software of JSCAST for precision high pressure die casting tooling, strong technical support for your new die casting parts design.

  Report including temperature field analysis, solidification analysis, velocity analysis.

  Facility including cold chamber die casting machines from 280T-1600T.

  all of our die casting machines equipped with automatic assistances, feeding manipulator, spraying manipulator, fetching manipulator, model constant temperature control system.

  400T die spotting machine.

  CNC precision mold engraving machines, deep hole drilling, five axle high speeding machining center, slow feeding machines, Testing machines including CMM, tensile testing machine, x-ray machine, metallographic analyzer.

  Company of LKM, ASSAB, UDDEHOLM, LK, BOHLER hade branch company not far away from us, this is great advantage for us to purchase high quality stand steel for our aluminum die casting molds, and high quality raw material for our custom die casting parts.

  The standard pressure die casting molds base from LK is precision and durable.

  We offer die casting mold design and technical support for potential customer.

  our main business is custom die casting parts service and custom die casting tools service.

  Main products including oil pan die casting mold, aluminum die casting housing for auto clutch, auto engine block, aluminum alloy shift fork, aluminum die cast sofa leg, aluminum die casting TV bracket, corrosion resistant light fixtures, casting bathroom light fixtures……
