Tt Series Of Vacuum Ceramic Filter - China

Working of special Ceramic Filter is based on the principle of the

micron pores, which takes the ceramics with micron pores as the filter

medium, by utillizing the solid liquid separating device designed by

adopting the principle of capillary function owe to their big quantity

of the micron pores and the round disk filter working under negative

pressure, making use of the special feature of the micron pores ceramic

plate through which the water can go and air can not pass, vacuuming the

inner chamber of the ceramic plate and establish the pressure difference

with the outside of the plate, and the suspending material can be

absorbed on the ceramic plate under the negative pressure while the

soild material stay on the surface of the plate because they can not go

through the micron pores ceramic plate, the liquid can be discharged or

recycled by passing through the plate and entering the gas-liquid

distribution device(vacuum drum)and thus achieve the goal of the solid-

liquid separating.

Operation Principle

One operating circle of the rotating parts (ceramic plate)can be divided into four sections: slurry secion , drying section , material discharge section, cleaning, and these four sections cycling continuously during the running of filter.

Product Application Areas

As the key product of the nation and brand product of Anhui Province, the TT serier ceramic filter has strong processing ability with borad applicable scope.

It has already successfully gained market access into 25 provinces of China and even some foreign counries such as Bengal, Kazakhstan, Armenia, South Koral, Zambia, Brazil, etc.

The TT series ceramic filter has been widely and successfully applied in numerous solid-liquid separation industry fields such as concentrated phosphate, concentrated copper, concentrated iron, iron tailings, concentrated gold , gypsum filtering, slag, nonmetallic ore, unclean acid and sewage process.

Product Feature

High efficient Energy saving and Environmental protection

Capacity increased by 50% than traditional vacuum filter.

And filter cake lower moisture, installed power is only 10% of traditional vacuum filter, but higher vacuum degree.

Filtrate can be recyled and solid amount of filtrate is lower than 50ppm.

Stable performance

Reasonable design, Carefully manufacturing.

And key parts all selected famous brands of domestic and international.

Such as: touch screen, PLC, frequency transformer, liquid level meter, metering pump, pressure transmitter and so on.

A high degree of intelligence

The production process by PLC automatic control.

Equipped with man-machine exchange interface.

Simple operation, mainenance convenient, system parameters can be easy adjusted, alarm function perfect and historical datd storage easy to search.

Filter board superior performance

Ceramic plate have a lot of advantages .

such as : uniform pore size distribution, high porosity, permeable rate good , high compression strength and so on.

Our company have the "Ceramic plate automatic spray membranes line", which is the only one in China.

We can made different filter according to custom's requirement.

Such as : alumina carbide and other material.

A kind of ultra high molecular weight PE material hollow one-piece filter board have a lot of advantages.

Such as: corrosion resistance, compressice and flexural strength, good filtering effect, wide application, light weight, recyclable and so on.

High polymer plate can be widely used on corrosion resistant material.

Such as: mines, chemical industry, metallurgy, titanium dioxde and so on.

Distributing valve device

We used the three point type of distributing valve, have a lot of advantages, such as: automatic regulation center, self pressing, reliable seal and so on.

Ultasonic cleaning system

According to the size of the material, distribution and corrosive conditons, we can equipped with different frequencies, different power ultrasonic system.

Equipped with ultrasonic box in body positioning type or lifting type.

Stirred device

According to the deuse, nasity of material and size distribution and other conditions, we can equipped with pneumatic type, mechnical oscillating type or mixing type of both to stirred the materials.

Prevent the tank material layering.

Back washing system

We have equipped with gas and water combination backwashing system or gas backwashing system, to ensure that filter and plate not be polluted by poor water, and prevent the material concentration suddenly reduced.

This system is very effective in taillings ultrafine particles materals.

Automatic drainage system

According to different type of machine .

We equipped with integral type or split type automatic drainage system.

This kind of system have a lot of advantages, energy saving, low fault rate, convenient field installation, no height requirements and so on.

Special cleaning device

Accoeding to the different physical and chemicak material causes the plate block up, company invented special cleaning machine, specil detergent and special solution, to dredge 80% area of plate, and make sure the plate can be recycle.
