Dy Series Single Cylinder Hydraulic Cone Crusher - China

Dy Series Single Cylinder Hydraulic Cone Crusher Larger Image

Single cylinder hydraulic cone crusher obtains the advantages of high technology, large capacity, high automation, energy saving and easy maintenance in crushing machinery.

DY/DYS series cone crusher has only one cylinder, who attaches one hydraulic device(security cylinder).

The discharging opening adjustment is through the up-and-down floating of main shaft to adjust the location of crushing cone part.

It is suitable to crush medium and above hardness ores and rocks with compression strength less than 300Mpa.

And it is widely used in metallurgy, building, highway, and chemical industries.

Structure and features

1 - Using laminating crushing theory, fine granularity.

2 - With dustproof structure and hydraulic protection device.

3 - Adopt curved bevel gear to longer the gear service life.

4 - Alternative various eccentricities and chamber types.

5 - With PLC control.

Model: DY560

Weight(t): 15.5

Motor Power(kw): 250 Chamber Type: EC

Max.

Feed Size(mm): 217 Discharge Opening Size CSS(mm)/Standard Capacity(t/h): 16/115-202; 19/123-279; 22/132-297; 25/140-316; 32/160-360; 38/177-399 Model: DY675

Weight(t): 29

Motor Power(kw): 315 Chamber Type: EC

Max.

Feed Size(mm): 280 Discharge Opening Size CSS(mm)/Standard Capacity(t/h): 16/180; 19/193-344; 22/207-444; 25/220-472; 32/250-557; 38/277-616; 44/303-674; 51/334-520 Note: 1 - Capacity changes under different work condition.

2 - Showed capacity based on feeding continuously with proportion of 1.6t/m3.

3 - Moisture content ≤4%, compression strength less than 300Mpa.

4 - Capacity various as for different material, for reference only.

Pre-sales Service

* Offer professional suggestions for equipment selection.

* The equipment can be modified the design according to

customers requirements besides standard model.

* Planning site and offer the suitable flow schemes.

In-sales Service

* Follow up on the progress of the production and quality of

the equipment.

* Ensure the delivery, offer relative drawings, and record the

trial run.

* To assistant customer checking and acceptance the

equipment.

After-sales

* Send professional technicians to assist in installation, commissioning and operation in production site.

* Training the operator and maintainer to ensure the normal operation of the equipment.

* For any troubles aroused under warranty, we will offer solutions within 48 hours and send technician to reach the site ASAP if needed.
