CRGS High Efficiency Single-Stage Double Suction Centrifugal Pump

General Description

CRGS pumps are new type of single stage double suction centrifugal split pump with high efficiency and performance.

It is widely used in delivering liquids to the water plant, circulation water system of air conditioner, pipe net system of supplying heated water, construction, watering, drainage pumping station, power station, industrial water supply system, and ship etc.

Performance range

Outlet diameter of pump DN 80—800mm

Capacity Q 22—116003/h

Head H 7—200m

Temperature T -20℃～105T 51;

Solid grains ≤80mg/l

Permitted working pressure ≤2.5Mpa

Instruction of pump type

CRGS300-700（I&# 65289;A

CR: Company code, means produced by CREDO PUMP

GS: High efficiency single stage double suction centrifugal pump

300: Outlet diameter is 300mm

700: The nominal diameter of impeller

(I): remodel design of impeller

A: A\B\C separately represents that outer diameter impeller cutting

Structure

*CRGS pumps are horizontally installed, the casing and the cover of the pump are divided along the axis.

*The pump cover is above the shaft and the casing is under the shaft.

*The inlet and the outlet are under the shaft.

*The centerline of inlet and outlet is perpendicular to the axis.

*The rotor can be removed without disturbing the inlet pipe and the outlet pipe, only dismantling the pump cover while maintenance.

*The shaft seal uses packing seals or mechanical seals.

The direction of rotation

The rotation for CRGS series pump is clockwise looking from the motor to the pump, for example, the pump inlet is on the right, and the outlet is on the left.

The motor can be connected with the other end of pump shaft according to customer’s requirements, meantime, the rotation, the direction of inlet and outlet are opposite to the above mentioned.

Material of main parts

The medium-contacting parts are made of cast iron.

The material of impeller: cast steel /brass /according to customer’s requirements.

Parts range

Pump, Motor, Coupling joint, Foundation plate and Mounting resistant cushion will be supplied when inlet diameter of pump is less than 200mm, more than 200mm inlet diameter will only supply pump, motor, coupling joint.

Remind:

Please indicate the material of main parts in your inquiry or purchase contract.

Any special requirement, please don’t hesitate to contact us.
