China Abrasion Resistant Testing Sieve Vibrate Screen - China

Application

Widely used in metallurgy, powder, chemical, medicine, building materials, geology, and national defense scientific research and production departments, laboratories, quality control rooms, institutions of higher learning lab, on the granular, powder particle size structure of materials, liquid type solids content and the amount of debris vibration screening, filtering, standard test sieve test

Features and Fuctions

1 - Test vibrating screen for lab use

2 - Particle distribution analysis

3 - Used in medicine, food, Chemicals.

Minerals.

Pharmaceuticals

4 - Rapidly replace the screen

5 - Standard Screen, ensure the high precision filtration

6 - Timer for setting as required

Work principle

Laboratory vibrating screen with new vertical vibration motor as vibration source, vertical vibration motor on both ends with partial heart heavy hammer.

Generating a horizontal , vertical , inclined three- dimensional motion.

Vibration force is passed through the screen frame chassis standard sieve box and materials toachieve excellent classification .

Technical parameters

Items Name unit Data

OneLayers Layer 1~8

TwoDiameter MmΦ 200Φ 100Φ 75

Three Granularity Mm0.038- 3

FourNoise DB≤ 50

Five Feeding

capacity

( once) G ≤ 200

Six Amplitude Mm≤ 5

Seven Voltage V 220

Eight Speed R/ min 1420

NinePower Kw0.125

Ten Overall

dimension Mm360×300×736

Eleven Weight Kg25
