Bucket Elevator Zhengzhou Mining Machinery - China

Introduction:

Bucket Elevator is composite by the shell, traction parts (chain), hopper, driving wheel (head wheel), bend wheel (tail wheel), tensioner, guider, feeding end (inlet) and the discharge end (outlet).

a, cylindrical bucket: deep bucket, bucket opening was 65 º tilt, high depth, and for drying, good flow, for good scattered granular material delivery

Shallow bucket: opening was 45 º tilt, low depth, for mobility and wet granular materials.

b, angular bucket: the side extent out the end board to form guard board, when discharging, the material flow along the guard board and floor, for the delivery of viscosity, large and heavy block of bulk materials

traction parts

(A) rubber belt: flexible gasket fixed with screws and connected to the belt end, with bucket width more than 35 ~ 40mm, generally belt can deliver materials no more than 60 ℃, heat-resistant belt can reach 150 ℃.

(B) chain: the single chain connected to the back board of hopper; the double chains connect on both sides of the hopper board.

Chain bucket elevator applies single chain when the bucket width is 160 ~ 2500mm, and applies double chains when the bucket width is 320 ~ 630mm, the main drawback of chain bucket elevator is high wear and frequency maintenance.

Working principle

The buckets scoop the material from the hopper, elevate them to the top and turn down after passing the head wheel, then discharge the material to the hoper.

The bucket elevator with transmission mainly applies rubber belt which set on the transmission cylinder.

The chain bucket elevator mainly has two parallel transmission chains.

On end has the transmission chain wheel and the other end is bend wheel.

The bucket elevator usually with shell to avoid dust spillage.
