50m3 Loading Capacity Wheel Belt Type Mining Muck Loader - China

50m3 Loading Capacity Wheel Belt Type Mining Muck loader

Product Description The multifunctional mine muck machine is a new type of loader developed to improve labor intensity and work efficiency.

The machine can directly transport rocks to the conveyor belt.

The machine adopts full hydraulic control mode, which is simple and convenient to operate.

The gantry frame of the machine is detachable and non-cut, which is convenient for installation in the well.

In addition, the height of the rear unloading can be adjusted according to the customer's own needs.

The machine is equipped with an adventure device to solve the danger of manual exploration.

This machine can be used in a cave below 2.2 meters, and the loading capacity per hour is between 40-60m³.

Application Mine slag raking machine is mainly used for phosphate ore, aluminum ore, iron ore, copper ore, gold ore, silver ore, lead-zinc ore and other mines, hydropower, tunnel projects in narrow-space mining operations.

And transportation, construction and loading.

The mining slag raking machine is a combination of a manipulator and a conveyor.

The slagging and conveying and loading functions are combined into one.

The production device adopts an electric full hydraulic control system.

It has the characteristics of safety, environmental protection, low energy consumption, and high efficiency.

It is an indispensable advanced mining equipment for mining enterprises and a substitute for labor and other machinery.

Specification

Model : ZWY50

Loading capacity m3/h : ≤50

Weight kg : 2700

Digging width mm : 2600

Digging height mm : 1600

Digging depth mm : ≤500

Digging distance mm : ≥1300

Gradeability ° : ≤5

Unloading height mm : 1200(Can be heightened)

Unloading distance mm : 1300(Can be lengthened)

Minimum turning radius ° : ≤5

Power kw : 11

Walking speed km/h : 1.45

Maximum passing size of material mm : 500×350

Wheelbase mm : 1300

Wheel distance mm : 1080

Adaptation dimensions m : 1.8×1.8

Product dimensions mm : 5000×1350×1500
