Handheld Hydraulic Comparison Test Pump Zt500 - China

Description Consisting of lever type hand pump, unloading valve, shut-

off valve, surge tank and pressure output interface, this handheld

hydraulic test pump is compact, easy-to-use and economical system to

manually generate and adjust pressure from atmosphere to as high as

100MPa in one time very stably, it can also generate large pressure

quickly and adjust pressure precisely at a set point.

Application

It is very suitable for use as the pressure generating and controlling component in calibration and testing systems using a digital or analog pressure indicator as a reference.

It is an ideal pressure generator for calibrating general pressure gauges, precision pressure gauge, pressure transmitter, differential pressure transmitter, pressure transducer, pressure switch and other pressure measuring instruments, it is extensively used in manufacturing, power, chemical, petroleum, metallurgy, aerospace, military industry as well as laboratory and fieldwork.

Features

Special high pressure sealing material, high reliability and extremely low leakage.

High quality screw press for fine pressure adjustments.

Built-in oil liquid filter which can filter the waste oil.

Simple structure, fast connection and easy operation.

Fine stainless steel, convenient maintenance.

Portable case with a self locking mechanism provided to protect them during transport and for fieldwork.

3 finger-tight fast pressure test ports.

Specification

Fluid media: transformer oil or any non-corrosive oil

Wide pressure range: 0~60Mpa / 0~100Mpa

Stability: 0.05％ F.

S

Adjust fineness: 0.1kPa

Dimension: 450mm*405mm*140mm

2 Output interfaces: M20*1.5

Weight: 15kgs

Accessories

1 - Manually operated hydraulic pressure generator 1 set

2 - Radial gauge fast connector （ZT50B-M14×1.5 5289; 2 pcs

3 - M20 Plug: 2pcs

4 - O-sytle rubber lock ring

Handheld Hydraulic Comparison Test Pump Zt500
