Tb Bucket Elevator - China
price: contact company for price
A mechanical machine consisting of a series of buckets attached to plate sleeve roller chains as its traction component and used to haul materials vertically.
Able to carry materials with bulk density less than 2 t/m³.
Elevating distance up to 45 m.
Able to handle materials of temperature not more than 250°C.
Installed with high strength plate chain made up from superior alloy.
Adopt several kinds of driving groups to drive which are securely framed and guard railed on driving platform.
Working Principle
A series of buckets attached to plate sleeve roller chains with sprockets located at the top and bottom, also known as the drive sprocket and divert sprocket.
The bucket is filled up with material and conveyed to the head terminal.
Under the centrifugal force of the parabolic design, the materials will be thrown from the bucket into the discharge chute.
Driving device drives the sprocket to operate the motion of conveying buckets in circular.
After discharging materials into the discharge chute, empty buckets driven back to the bottom and repeat the process.
Features and Advantages
High stability and reliable operation.
High conveying speed with smooth transmission.
High capacity.
Installed with backstops to prevent chain swinging during operation.
Securely sealed body, therefore low noise pollution.
Low driving power, hence low energy consumption.
Long operation span.
Applications
Widely used in mining, metallurgy, chemicals, power plant, agriculture, quarry industries etc.
to transfer materials in the form of powder, granular and grinding block such as coal powder, slag, limestone, cement raw material, cement clinker, coal and dry clay.
Company Contact:
- Posted By: Henan Pingyuan Mining Machinery Co., Ltd
- Phone: 86-373-5890799
- Address: No. 289, Yellow River Road, Xinxiang City, Henan , China
- Email:
- Website: http://www.pkmachinery.com
Published date: August 26, 2016
- Business Description: Designing and manufacturing YA/YK circular vibrating screen, PXZS gyratory vibrating screen, ZS linear vibrating screen, TD75/DT2A belt conveyor, DJB/DJS corrugated sidewall belt conveyor, TH/TD bucket elevator, TDG/THG high efficient bucket elevator, LS/GX screw conveyor, MS/MC scraper conveyor, DY portable belt conveyor, ZG vibrating feeder etc.
for use throughout the processing and handling industries.
