Mosi2 Heating Elements Heater Rods - China

d = the diameter of hot zone

c = the diameter of cold zone

Le = the length of hot zone

Lu = the length of cold zone

YL- Molybdenum disilicide ( MoSi2) heating element is a resistance generate- heating component made from MoSi2 or the basic material.

It is used in high temperature under the oxidizing atmosphere, it looks like glass in its surface and form a light SiO2 glass film which can protect the element not to be oxidized.

So this kind of element has unique effect for resisting oxidization in the high temperature.

It is used to the highest temperature up to 1800C during oxidizing atmosphere.

According to your request, our company can produce the products of Pole, ”I” ' U' , ' W' and ' U' - right angle shapes, etc.

MoSi2 heating element can usually make use of furnace temperature from 1300C to 1800C.

It is extensively used in the industries of metallurgy, glass, ceramic refractory, crystal electronic device, industrial furnace manufacture, etc.

.

It is an essential ideal element when the products are sintering in the high temperature.

Sizes:

YL- 1700℃ Grade YL- 1800℃ Grade

d/ c ( mm)

Le Max, mm

Lu Max, mm

a ( mm)

n ( mm)

g ( mm)

Nonstandard size could be made according to your requirement.

When you place order, pls kindly tell us the following things

Diameter of Hot Zone ( D1) : mm

Diameter of Cold End ( D2) : mm

Length of Hot Zone ( Le) : mm

Length of Cold End ( Lu) : mm

Shank spacing ( A) : mm
