marine double suction mid-open horizontal centrifugal pump

China Deyuan Marine Fitting Co., ltd are leading supplier of marine pumps, such as marine diesel emergency fire pump, vortex marine water pump, marine centrifugal water pump etc.

Pls contact us for more details.

The CWS type pump is a single-stage double suction mid-open horizontal centrifugal pump.

It is used to deliver the fresh water and the liquids physically and chemically similar to water.

If the overflow component is made of stainless steel or coated with SEBF high-performance epoxy powder coating, it can also be used to deliver the corrosive liquids.

The maximum temperature of the delivered liquids shall not exceed 80C.

It is suitable for water supply and drainage in factory, mining ore, city and power station as well as for flood control and irrigation works of agricultural fields.

It always used in the capital ship and Float Boatyard.

The pump rotates anticlockwise viewed from motor.

Type (50HZ, 3phase, 380v)main technical parameter Power (kw)

Capacity

(m3/h) Head

(m) Speed

(r/minZ) NPSHR

(m) Shaft power

(kw)

150CWS-8.5 125 54 2950 25.2 37

160 50 3.8 28.1

200 4229.7

150CWS-8.5A 105 44 2950 17.5 30

140 40 3.8 20.3

170 3521.9

150CWS-8.5B 100 39 2950 16.3 22

130 36 3.1 18.2

160 3219.4

150CWS-6 125 84 2950 39.7 55

160 78 3.3 46.9

200 7052.2

150CWS-6A 105 65 2950 27.3 45

140 60 3.3 31.8

170 5435.7

200CWS-13 210 48 2950 33.9 45

280 42 6.3 39.3

335 3540.4

200CWS-13A 200 43 2950 30.8 37

270 36 6 33.1

325 3034.9

200CWS-9 210 68 2950 50.2 75

280 63 5.7 60.4

335 5864.1

200CWS-9A 180 55 2950 36.4 55

245 48 5.5 41

295 4042.8

More types can be offered, pls contact us directly for more details.

&&&&&
