Jct Stainless Steel Twin Paddle Mixer - China

JCT stainless steel twin paddle mixer

1 Working principle:

The JCT series stainless steel twin paddle mixer is comprised of vertical cone-shaped tank, two asymmetric screws, fixed or full-open top cover, arms, transmission unit.

Two (single or three) screws rotate along their own central axis, we call this movement self-rotation; the arm drive the two screws rotate along the wall of mixing tank, we call this movement revolution.

The self-rotation makes the materials elevated; the revolution makes the materials diffused in the radial; the materials elevated with self-rotation forms two material flows and fall down to fill in the material vacancy, at the bottom; so the triple compound movement make materials homogenously mixed inside the nauta mixer tank.

2 Performance & features of JCT stainless steel twin paddle mixer:

2.01 Material: stainless steel 304 / 316L or mild steel Q235;

2.02 Surface treatment: paint (mild steel), polish/sandblasting (stainless steel);

2.03 Agitators: shaft with welded screws;

2.04 Mixer tank: vertical, conical tank;

2.05 Shaft: two (single or three);

2.06 Mixing time: 5-30 minutes;

2.07 Working model: batch mixing;

2.08 Speed reducer: cycloid reducer;

2.09 Rotation speed: fixed speed;

2.10 Seal: oil seal or other seal;

2.11 Openings: feeding inlet, manhole, and inspection & connection port;

2.12 Discharge valve: manual dislocation (plum blossom) discharge valve;

2.13 Working condition: NPT (normal pressure and temperature);

2.14 Not heavy duty: mixer can not be started with loading materials;

2.15 Power supply: 220V 50HZ single phase/ 380V 50HZ 3 phase;

2.16 Non ex-proof electronics (motor, electronic elements, control cabinet);

3 Optional features of JCT stainless steel twin paddle mixer:

The following optional features are available: wear-resistant and anti-corrosion materials, surface treatment; single (two or three) screw shafts; continuous mixing; gear box reducer; changeable speed; customized openings and discharge valves; temperature control; pressure requirement; heavy-duty configuration; motors, electronic elements, electronic control panel are customized to different power and ex-proof requirements; light glass; sampling device; liquid spraying device; scrappers etc.
