High Lift Reach Stacker - China

Stability 1 - The large and strong chassis ensures sufficient stability of the forklift, with lifting height range from 3 to 6.2 meter.

2 - Steel of mast is imported from Germany offers superior stability and safety.

3 - Large and comfortable compartment with adjustable seat reflects a concept of ergonomic design.

The stand type cab gives big operation space, offers the best visibility.

4 - Rear axle is equipped with two separate floating devices, enhances stability in terms of structure, reduces the self-weight, and prolongs the use time of the driving wheel.

Safety and high efficiency 1 - Have safety travelling speed limited device in the mast, Travelling speed will automatic lowering when forks height is up 5M.

2 - Use double controllers to realize stepless speed regulation of travelling of both lifting and travelling.

3 - Full hydraulic steering system makes turning easy and flexible.

4 - Adopt hydraulic brake for two front wheel and electric brake for electric brake for driving motor, offering simple operation for travelling and braking.

Easy maintenance 1 - RUYI self design mast which doesn't need to disassemble it from truck body when replace roller of the mast.

2 - For daily maintenance of the battery requires to pull out the battery box from inside the truck frame.

We offer both

(1)side way roller battery changing for high using truck

(2) automatic mast -push- out and pull-in function for normal daily maintenance.

3 - Bolt fixed back cover is easy to open for daily maintenance.

Option · AC power system · Joystick hydraulic controller · LCD display and camera · High lever positioning device
