Ged Vacuum Distillation Waste Oil Regeneration System - China

Application

NSH GED Black Oil Distillation Systems are able to regenerate a variety of used oil, engine oil, transformer oil, gear oil, hydraulic oil, washing oil, rubber oil, etc.

After the distillation treatment, vacuum treatment and regeneration treatment through GED system, you can get base oil of good quality and a small amount of gasoline and diesel oil.

Edges of GED

Vacuum assisted distillation and gaseous hydrocarbon diversion technology

The advantages of negative pressure distillation and gaseous hydrocarbon diversion are that the distillation temperature can be greatly optimized, which not only can reduce the energy consumption, but more importantly can greatly improve the yield of the single unit and oil quality.

Heating system

The fuzzy control theory is adopted to design the heating control method.

No acetylene hydrogen is generated during the heating process, the heating is even and the oil temperature is stable, and the function of automatic constant temperature and over-temperature protection is provided.

This is a patented technology belongs to NSH company.

Highly automated control

Equipment with high automation control devices, only 2-3 people are needed to operate one set of equipment;

Perfect equipment protection system

① Over-temperature protection.

When the abnormal situation, the heater will cause a sharp increase in oil temperature, but when the oil temperature exceeds the set limit temperature, heating protection will automatically cut off the power and alarm.

② Over-pressure protection.

The use of the products from United States Cavert Company, when the pressure exceeds the limit set, the pressure protection device will automatically cut off the pump power and alarm.

③ With the over-current, overload, lack of phase, undervoltage and other electrical protection; With oil pump, vacuum pump, heater trinity interlock protection circuit; With pump motor-controlled interlock circuit to protect the motor and electrical components safe.

④ With the power phase sequence protection, to prevent damage to the pump head when phase sequence adjustment.

⑤ Vacuum gauge and pressure gauge are Radar products, to monitor the working condition of oil system, indicating the standard.

⑥ With work status display of vacuum pump, oil pump, heater and else.

The working status of the whole machine is indicated by the indicator light, and the parts and components adopt the first-line brand products from domestic and international.

Excellent performance and reliable, low failure rate.

⑦ Electrostatic protection system: This design is based on GB 13384-2009 "Liquid Petroleum Product Static Safety Regulations".

The sealing material is PTFE, anti-static connection using oxygen-free copper foil material, ground material using oxygen-free copper material to prevent damage to static electricity protection, anti-static treatment according to national standards;

⑧ Explosion protection: involving level control, lighting, alarm and other electrical control point of the control box, voltage levels are in accordance with GB 3836-2010 "explosive gas environment with electrical equipment", reach Exd Ⅱ design requirements;

The structure of the whole machine is simple and easy to maintain and repair, with beautiful appearance.
