Fdt 0101 Open Cup Flash And Fire Point Tester - China

Scope

The instrument is in the People's Republic of China in accordance with standard GB / T3536 "flash point of petroleum products and the determination of the Cleveland open cup flash point of law" under the requirements of design and manufacture, except for the determination of fuel oil and a flash point below 79 ℃ opening outside petroleum products and bitumen flash point and fire point.

Features

1, using a special form of furnace, ensure the safety of trial; heating power continuously adjustable to meet the test requirements.

2, the instrument is designed for desktop structure, stainless steel countertops and stainless Gang Gang furnace shell, beautiful and generous.

3, the instrument is complete, users simply accompanied by gas or other civilian combustible gas can be tested.

4, covered with the flame is extinguished, in line with the requirements of ignition test.

Technical Parameters

1 Power supply: AC 220V ± 10%, 50Hz.

2, the heating device: quartz tube furnace heat, no fire, explosion, power 0~600W continuously adjustable.

3, designated sweeping device: automatic sweep program.

4, thermometer: -6 ~ 400 ℃, dividing 2 ℃, technical conditions are met petroleum products testing liquid thermometer technical conditions GB provisions / T514's.

5, the ignition device: ⑴ ignition sources: gas (or other civilian combustible gas, the same below);

⑵ spout aperture: 0.6~0.8 mm.

6, ambient temperature: -10 ℃ ~50 ℃.

7, the relative humidity: ≤85%.

8 - Total power consumption: less than 650W.
