Yuka Brand High Efficiency Industrial Compressed Air And Water Separator Inlet Outlet 1 5 - China

YUKA WS100 High Efficiency water separator

1 - Max.

working pressure: 1.6Mpa.

2 - Flow Rate(m3/min) : 10.0

3 - Inlet: Rc1-1/2'

Water separator is one of purification products without elements which is used to before air filter protect coalescing filters against bulk liquid contamination , where excessive cooling takes place in air receivers and distribution piping.

Technical data

Brand: YUKA

Model: WS50

Pipe size: Rc1'

Flow rate: 4.5m3/min

Materials: Alluminuim alloy

Made way: Die casting

Funtion: Separate water and gas

Aluminium alloy die-cast housings with long time use.

Keep 99% separation effect.

Attach parts drain , liquid mirror, manual drain.

The max working pressure: 1.6Mpa.

The max.

temperature is80°C.

The lowest temperature is 1.5°C.

Differential pressure is 0.007Mpa

Anti-corrosion treament

International Certification Approva

Water Separators Working Principle

Wet air enters the inlet port and is directed into the separator module fixed turning vanes causing the

air to spin inside the vessel and then change direction as it passes the impinger.

A vortex is then created which narrows and intensifies as it reaches the lower part of the

separator.

Bulk liquid is therefore removed from the air stream due to a combination of:

Directional changes of the air stream.

Velocity changes.

Centrifugal action of the vortex.

As the vortex reaches the bottom of the separator

module, air is forced through the centre of the vortex.

Aerospace turning vanes located in the outlet of the separator module now turn an “inefficient

corner” into a number of more “efficient corners” to reduce turbulence, minimise pressure loss and

therefore operational costs
