Application:

In the electric power industry, insulating oil is wildly applied in electric equipments.

The dielectric strength is a comprehensive index for insulating oil.

Series IIJ- II oil tester is special for testing insulating oil' s dielectric strength.

IIJ- II Automatic oil tester is designed according to international standard of IEC156 - Adopt industrial single chip as controller, apply large integrate circuit, new type I/ O interface, LCD displayer, combined with special testing and anti- jamming technologies which greatly improve the tester' s performance.

Features:

1 - Simple operation, high degree of automation ( just press a button)

2 - Using the menu management, easy to understand the input parameters

3 - Can store 99 groups oil sample test data to facilitate future access to and print, test data can be stored in power off state for 10 years.

4 - The system clock in the power off state can continue to run.

5 - Through the RS232 port with a software upgrade or with the PC, on- line detection.

6 - Anti- interference ability

7 - Detection with high precision

8 - Small size, light weight, easy operations

Technical Parameters:

1 - Power supply: AC220V+( - ) 10% , 50Hz

2 - Output voltage: 0 to 100KV( 60KV, 80KV, 100KV)

3 - Capacity: 1.2KVA( 1.6KVA, 2.0KVA)

4 - Speed of pressure rise: about 2KV/ S

5 - Voltage test precision: +( - ) 3%

6 - Breakdown sensitivity: <2KV

7 - Wave difference: <3%

8 - Time of breakdown: <10ms

9 - Working condition

temperature: 0C to 40C humidity : The biggest comparatively humidity85%

10 - Reserve circumstance

temperature : - 20C to 60C humidity : The biggest comparatively humidity75%

Working altitude: <1500m ( if over 1500m can be designed specially)

11 - Dimension: 480mm* 460mm* 460mm
