Temperature Humidity Chamber - China

Environmental Chamber

Environmental chamber is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.

The environmental chamber for conditioning of samples prior to testing, It also can be used for a variety of materials of high – low temperature alternating test.

The test for temperature, humidity, time can be programmed.

Provides conditions of temperature from -70 degree to +180 degree and of humidity form 10% to 98%.

● The ideal simulation environmental chamber for all heat and cold testing between -70 ºC and 180 ºC temperature range.

● Well suited for reliability testing based on current test standard in the temperature range of -70 °C to 180 °C & 10% to 98% RH.

● This design SUS environmental chamber meet all requirements for extreme testing and low temperature alternating climate profiles from -70 °C -180 °C with humidity Temperature adaptability test under the condition of rapid change, or gradient for electrical, electronic, instruments and other products or spare parts, particularly applies to environmental stress screening test (ESS).

Benefits more than you can get from other supplier.

● Delicate touch screen sight and excellent user experience.

● Unique and compact design, top grade appearance, stable performance and easy operation.

● Environmental chamber can simulate a wide range of temperature and humidity environments.

● Capable of testing large components, assemblies, and finished products.

● Customized sizes and configurations available, Environmental test chamber.

environmental chamber Model # TW-064 TW-080 TW-150 TW-225 TW-408 TW-800 TW-1000

Test Volume 64L 80L 150L 225L 408L 800L 1000L

Temperature Range -60℃~ +150℃ -70℃~ +150℃ -70℃~ +150℃ -65℃~ +150℃ (180℃) -70℃~ +(180℃) -70℃~ +150℃ (180C) -70℃~ +180℃

Humidity Range 20%~ 95% 10%~ 95% 10%~ 95% 10%~ 98% 10%~ 98% 20%~ 95% 10%~ 95%

Temp Uniformity ±0.5~ ±1.0℃ ±0.5~ ±1.0℃ ±0.5~ ±1.5℃ ±0.5~ ±1.5℃ ±0.5~ ±1.0℃ ±1.0~ ±2.0℃ ±1.0~ ±2.0℃

Heating Rate 2℃~ 3℃ 2℃~ 5℃ 2℃~ 5℃ 3℃~ 5℃ 3℃~ 5℃ 4℃~ 5℃ 3℃~ 5℃

Cooling Rate 1℃~ 2℃ 1℃~ 2℃ 1℃~ 2℃ 1.5℃~ 2℃ 1.5℃~ 2℃ 2℃~ 3℃ 2℃~ 3℃

Refrigerant R404A R23 R508 R404A R23 R508 R404A

Compressor Tecumseh (France) Bizter (Germany) Tecumseh (France) Bizter (Germany) Tecumseh (France) Bizter (Germany) Tecumseh (France)

Control System TEMI 880 TEMI 1500 TEMI 2700 KOREA OYO 1200 JAPAN OPTIONAL

Inner Size (W*D*H) 400x400x400 400x400x500 500x500x600 500x600x750 600x800x850 1000x800x1000 1000x1000x1000

Outer Size (W*D*H) 900x600x1200 900x960x1360 1000x1060x1460 1000x1160x1610 1100x1300x1710 1480x1310x1840 1480x1510x1840

Gross Weight 250 Kgs 290 Kgs 350 Kgs 420 Kgs 550 Kgs 620 Kgs 780 Kgs

Company Contact:

• Posted By: WEWON ENVIRONMENTAL CHAMBERS CO., LTD

• Phone: +8613694972540

• Address: Sangyuan Industrial Zone, Dongguang , Select One:, China

• Email:

• Website: https://www.wewontech.com/

• Business Description: Wewon Environmental Chambers Co., Ltd. as a manufacturer and supply environmental test chambers , climatic chambers , xenon test chambers, walk in chambers … for abroad partners many years !

  Welcome To Wewon Environmental Chambers Co., Ltd. With 18-plus years of experience, Wewon Environmental Chambers is a professional manufacturer of high-performance environmental chambers, Walk-in chambers, xenon test chambers, ozone test chambers, & vibration test systems.

  tulips

  Wewon Environmental Chambers Co., Ltd. is a leading China manufacturer specialized in supply environmental test chambers !

  Wewon Environmental Chambers has a highly qualified, highly skilled workforce and owns a provincial high-tech enterprise research and development center with four senior engineers, six cooling sytem engineers, a total of 16 scientific and technological personnel specializing in electronic & cooling technology, software development, mechanical design, standardization and various other fields.

  Year 2017 Testimonial Notice by Tanker Yuan

  But I must explain how Wewon Environmental Chambers

  “Now Wewon Environmental Chambers possessed more than 30 types of testing equipment: high and low temperature humidity test chambers, xenon test chamber, oven, accelerating weather tester, UV chamber, ozone chamber, salt spray chamber… With the help of this equipment it is possible to do analysis of environmental adaptation and to run test programs for all currency counters, money detectors, other than EMC”

  We supply you the environmental test chamber with fast shipping time, competitive price, and good qualty ! Contact us now !

  ● Features 1: Fast Lead Time, Ready and shipping an environmental chamber 30% faster then China suppliers.

  ● Features 2: With Competitive Price, There many China local distributor come and buy environmental chambers from us.

  ● Features 3: Good Quality Guarantee, The main parts we choose France Tecumseh, Germany Bitzer, Korea TEMI, Japan OYO…

  ● Features 4: 100% QC Check before shipment.

  There has 2 times check, during manufacture and before shipment.

  ● Features 5: Good Service System.

  There has a service team with can help the customer via remote assistance by internet.

  ● Features 6: CE, ISO System.

  The environmental test chambers has got the CE, ISO system approval.

  ● Features 7: Accept OEM.

  ODM Orders.

  We accept to make your brand /logo on our environmental chambers.

  ● Features 8: Real Factory Guarantee.

  We are the real environmental test chambers manufacturer, Its so important for a long term cooperation.
